LOVOL TD824-1F461F38K Tractor Parts Catalogue 02

Meppon Parts Posted on by






TD800.201A 20.1-手油门操纵总成 20.1-HAND THROTTLE CONTROL ASSSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

TA700.201A-01

手油门总成

HANDLE THROTTLE ASSEMBLY

1

2010-06_

2

GBT93-6-A0P

弹簧垫圈

SPRING WASHER

3

2011-11_

3

GBT5781-M6X25-A2L

六角头螺栓

BOLT

3

2011-11_

4

FT700.20.324

手油门盖

HAND THROTTLE COVER

1

2011-11_

5

GBT5780-M10X45-A3L

六角头螺栓

BOLT

1

2011-11_

6

GBT96-10-A0P

垫圈

WASHER

1

2011-11_

7

GBT68-M8X45-A2L

开槽沉头螺钉

SCREW

3

2011-11_

8

FT650.20.133

紧固螺钉

LOCKING SCREW

1

2011-11_

9

GBT97.1-8-A0P

平垫圈

WASHER

1

2011-11_








TA700.202B 20.2-脚油门总成 20.2-FOOT THRORRLE ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

FT650.20.101

脚踏板

FOOT PEDAL

1

2011-11_

10

FT650.20.011

脚油门摇臂焊合

FOOT THROTTLE ROCKER ARM WELDMENT

1

2011-11_

11

GBT93-8-A0P

垫圈

WASHER

2

2011-11_

12

FT650.20.104

扭簧

TORSION SPRING

1

2011-11_

13

FT65.45.393

油门踏板密封套

THROTTLE PEDAL SEAL SLEEVE

1

2011-11_

2

GBT879.1-5X20-A0P

销

PIN

2

2004-01_

3

FT800.20.013

脚踏板摇臂焊合

FOOT PEDAL ROCKER ARM WELDMENT

1

2011-11_

4

FT650.20.107

橡胶塞

RUBBER RING

1

2011-11_

5

GBT5781-M8X45-A2L

六角头螺栓

BOLT

1

2011-11_

7

GBT5781-M8X20-A2L

六角头螺栓

BOLT

2

2011-11_

7

GBT5781-M8X20-A2L

六角头螺栓

BOLT

2

2011-11_

8

FT650.20.108

油门支架

THROTTLE PEDESTAL

1

2011-11_

9

FT650.20.114

手油门摇臂

HAND THROTTLE ROCKER

1

2011-11_








TD800.203 20.3-拉线总成 20.3-PULL WIRE ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

1

1

2

3

TA550.203A.2 FT800.20.014a TD800.203.1 GBT97.1-6-A0P GBT91-2×12-A0P

脚油门拉线总成脚油门拉线总成脚油门拉线总成平垫圈

开口销

FOOT THROTTLE WIRE ASSEMBLY FOOT THROTTLE WIRE ASSEMBLY FOOT THROTTLE WIRE ASSEMBLY WASHER

PIN

1

1

1

2

2

2007-12_



2006-08_

2009-05_

2009-05_








FT800.21C.001 21-离合器总成 21-CLUTCH ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

L-03031-0757-04

副离合器从动盘总成

AUXILIARY CLUTCH DRIVEN PLATE ASSEMBLY

1

2011-11_

10

L-02615-0051-02

主分离杆总成

MAIN RELEASE LEVER ASSEMBLY

3

2011-11_

2

L-02103-0733-00

副离合器压盘

AUXILIARY CLUTCH PRESSURE PLATE

1

2011-11_

3

L-04130-0003-01

膜片弹簧

FILM SPRING

1

2011-11_

4

L-02165-0105-01

支承圈

SUPPORT WASHER

1

2011-11_

5

L-00454-0002-00

弹性圆柱销

PIN

1

2011-11_

6

L-02103-0732-10

主离合器压盘

MAIN CLUTCH PRESSURE PLATE

1

2011-11_

7

L-03031-0117-00

主从动盘总成

MAIN DRIVEN PLATE ASSEMBLY

1

2011-11_

8

L-02101-0215-06

离合器壳

CLUTCH HOUSING

1

2011-11_

9

L-02615-0031-02

副分离杆总成

AUXILIARY RELEASE LEVER ASSEMBLY

3

2011-11_








FT800A.21C.002-1 21.1-离合器操纵总成-1 CLUTCH CONTROL ASSEMBLY-1



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

FT800A.21.043

副离合操纵把手总成

AUXILIARY CLUTCH CONTROL HANDLE

1

2011-11_

1.1

FT800A.43.065

制动联锁杆焊合

ASSEMBLY

1

2011-11_

1.1

FT800A.21.045

按钮总成

BRAKE CONNECTING LOCK ROD WELDMENT

1

2011-11_

1.11

FT800A.21.323

销

BUTTON ASSEMBLY

1

2011-11_

1.12

FT800A.21.337a

副离合拉杆

PIN

1

2011-11_


AUXILIARY CLUTCH PULL ROD



1.13

FT800A.43.310

棘轮



1

2011-11_

1.14

GBT894.1-13

轴用弹性挡圈

RATCHET WHEEL

2

2009-04_

1.15

FT800A.21.321

销轴

SNAP RING

1

2011-11_

1.16

FT800A.21.065

副离合操纵把手固定座合件

PIN

1

2011-11_

1.2

FT800A.21.319

操纵把手套

AUXILIARY CLUTCH CONTROL HANDLE FIXING

1

2011-11_


SEAT UNIT



1.3

FT800.43.180

弹簧

CONTROLLING HANDLE SLEEVE

1

2011-11_

1.4

FT800A.21.315

顶杆



1

2011-11_

1.5

FT800A.21.320

护罩

SPRING

1

2011-11_

1.6

GBT68-M4X10-4.8-A2L

开槽沉头螺钉

TOP ROD

4

2009-04_

1.7

FT800A.21.322

小销轴

BONNET

1

2011-11_


SCREW



1.8

FT800A.21.044

操纵把手总成

SMALL PIN SHAFT

1

2011-11_

1.9

FT800A.21.314

棘爪



1

2011-11_

10

GBT894.1-30

挡圈

CONTROLLING HANDLE ASSEMBLY

1



11

GBT882-B10X30

销轴

PAWL

1

2004-01_

12

GBT848-10-A0P

小垫圈

RETAINER RING

1

2004-01_


PIN



13

GBT91-3.2X20-A0P

开口销

WASHER

1

2004-01_

13

GBT91-3.2X20-A0P

开口销



1

2004-01_

14

GBT848-30-A0P

小垫圈

PIN

1

2004-01_

15

FT800A.21.070

副离合支撑轴焊合

PIN

1

2011-11_

2

GBT5781-M8X30-A2L

六角头螺栓

WASHER

2

2004-01_








FT800A.21C.002-1 21.1-离合器操纵总成-1(续)



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

3

4

5

6

7



8

9

GBT93-8-A0P GBT41-M8-5-A2L

GBT5781-M8X16-A2L GBT6171-M10X1-A2L FT800.21.240



GBT5781-M10X30-A3L GBT93-10-A0P

垫圈

六角螺母 六角头螺栓螺母

拉杆前叉



六角头螺栓

标准型弹簧垫圈

WASHER HEXAGON NUT BOLT

NUT

PULL ROD FRONT FORK



BOLT WASHER

4

4

2

1

1



4

4

2004-01_

2004-01_

2004-01_

2004-01_

2011-11_



2004-01_

2004-01_
