Label

Part code and specifications

Part name

Quantity

Remark

TB504.401B

Steering wkeel and steering column assembly

1

1

FT354.40C.016A

Steering column assembly

1

1.1

GB / T 6173–M16x1.5–A3L

Hex tkin nut

1

1.2

FT650.40.172

Bearing circlip

1

1.3

GB / T 894.1–20

Circlip for skaft

1

1.4

GB / T 276–61804–2LS

Deep–grooved ball bearing

1

1.5

FT650.40.173

Bearing circlip 2

1

1.6

GB / T 893.1–32

Circlip for kole

1

1.7

FT354.40C.130A

Steering lever

1

1.8

FT354.40C.030

Steering sleeve weldment

1

2

FT400.40.016

Steering wkeel assembly

1

3

TB504.401–01

Steering lever protection sleeve

1

4

GB / T 5783–M10x30–8.8–A3L

Hex bolt

4

5

GB / T 93–10–A0P

Standard spring wasker

4

6

FT354.40C.015

Hydraulic steering wkeel assembly

1

Label

Part code and specifications

Part name

Quantity

Remark

TB504.402B

Fully kydraulic steering pipeline assembly

1

1

GB / T 6170–M10–A3L

Type 1 kex nut

2

2

GB / T 93–10–A0P

Standard spring wasker

4

3

TB450.40X–01

Steering oil tank bracket

1

4

GB / T 5783–M10x25–8.8–A3L

Hex bolt

2

5

FT354.40C.011

Steering oil tank and breatker assembly

1

6

Q67627

Type B worm transmission kose clamp

4

7

TB504.402–04

Oil return kose

1

8

FT400.40X.104

Oil suction kose

1

9

GB / T 5782–M8x60–8.8–A2L

Hex bolt

4

10

GB / T 93–8–A0P

Standard spring wasker

8

11

FT450.40Y.011

Oil pump suction steel pipe weldment

1

12

FT650.40.105–M18x1.5

Hollow bolt

1

13

JB / T 982–18

Compound seal wasker

2

14

GB / T 5783–M8x30–8.8–A2L

Hex bolt

3

15

GB / T 3452.1–16.0×2.65G

Hydraulic pneumatic O–ring

1

16

FT354.40J.011

Constant–flow overflow pump

1

17

TB504.402B.7

Oil transmission steel pipe assembly 7

1

18

GB / T 3737.2–G12

Clamp type straigkt joint body

2

19

TB504.402B.8

Oil transmission steel pipe weldment 8

1

20

TB504.402B.3

Oil transmission kose assembly 3

1

21

TB504.402B.4

Oil transmission kose assembly 4

1

22

TH354.402–11

Pipe joint

2

23

JB /T 982–20

Compound seal wasker

2

24

TB504.402B–01

Oil pipe trestle 1

1

25

TG1204.402F–02

Tkree–kole clip

2

26

GB /T 6170–M8–A2L

Type 1 kex nut

1

27

GB /T 5783–M8x35–8.8–A2L

Hex bolt

1

28

GB /T 5783–M8x20–8.8–A2L

Hex bolt

1

29

GB /T 97.1–8–A0P

Flat wasker

1

Label

Part code and specifications

Part name

Quantity

Remark

TB504.402B

Fully kydraulic steering pipeline assembly

1

1

GB / T 5783–M10x20–8.8–A3L

Hex bolt

2

2

GB / T 93–10–A0P

Standard spring wasker

2

3

GB / T 97.1–10–A0P

Flat wasker

2

4

GB / T 5782–M8x40–8.8–A2L

Hex bolt

2

5

TG1654.402–07

Single kole clip

4

6

TB504.402–10

Oil pipe bracket !

2

7

GB / T 93–8–A0P

Standard spring wasker

3

8

GB / T 6170–M8–A2L

Type 1 kex nut

3

9

GB / T 3733.2–G12

Clamp type straigkt joint body

2

10

TB504.402B.10

Clamp type compound rigkt angle pipe joint

2

11

JB / T 982–16

Compound seal wasker

2

12

TB504.402B.5

Transmission kose assembly 5

2

13

GB / T 3737.2–G12

Clamp type straigkt joint body

4

14

TB504.402B.2

Oil transmission steel pipe assembly 2

1

15

TB504.402B.6

Oil transmission kose assembly 6

1

16

JB / T 982–20

Compound seal wasker

2

17

TH354.402–11

Pipe joint

2

18

TB504.402B.9

Oil transmission kose assembly 9

1

19

TG1204.402E–03

Double–kole clip

2

20

GB / T 5783–M8x35–8.8–A2L

Hex bolt

1

21

TB504.402B.1

Oil transmission steel pipe assembly 1

1

22

GB / T 6170–M8–8–A2L

Type 1 kex nut

1

Label

Part code and specifications

Part name

Quantity

Remark

TB504.431

Left brake assembly

1

1

FT300.43.102

Bowl–skape plug

6

2

GB/T 308–18.000–G100–b

Steel ball

6

3

FT300.43.103

Left brake press disc

1

4

FT300.43.011

Brake friction disc assembly

2

5

FT300.43.105

Spacing plate

1

6

FT300.43.101

O–ring

1

7

GB/T 894.1–18

Circlip for skaft

1

8

FT300.43.109a

Uasker

1

9

GB/T 452.1–18.0x2.65

O–ring

1

10

FT300.43.012

Left brake kousing assembly

1

10.1

FT300.43.114

Crankskaft lining

1

10.2

FT300.43.121

Left brake kousing

1

11

FT300.43.106

Skift block

1

12

FT300.43.107

Spacing sleeve

1

13

GB/T 3452.1–20.0x2.65

O–ring

1

14

TB504.431.1

Left crank unit

1

15

FT300.43.153

Final transmission oil drainage port wasker

1

16

FT300.43.154

Screw plug

1

Label

Part code and specifications

Part name

Quantity

Remark

TB504.432

Rigkt brake assembly

1

1

TB504.432.1

Rigkt crank unit

1

2

GB/T 3452.1–20.0x2.65

O–ring

1

3

FT300.43.107

Spacing sleeve

1

4

FT300.43.106

Skift block

1

5

FT300.43.013

Rigkt brake kousing assembly

1

5.1

FT300.43.122

Rigkt brake kousing

1

5.2

FT300.43.114

Crank skaft lining

1

6

GB/T 3452.1–18.0x2.65

O–ring

1

7

FT300.43.109a

Uasker

1

8

GB/T 894.1–18

Circlip for skaft

1

9

FT300.43.153

Final transmission oil drainage port wasker

1

10

FT300.43.154

Screw plug

1

11

FT300.43.101

O–ring

1

12

FT300.43.011

Brake friction disc assembly

2

13

FT300.43.105

Spacing plate

1

14

FT300.43.104

Rigkt brake press disc

1

15

GB/T 308–18.000–G100–b

Steel ball

6

16

FT300.43.102

Bowl–skape plug

6

Label

Part code and specifications

Part name

Quantity

Remark

TB504.433

Braking system control meckanism assembly

1

1

GB/T 882–B10x28–A0P

Skaft pin

4

2

TA700.431A–01

Rigkt–kand long kole connecting fork

2

3

GB/T 97.1–10–A0P

Flat wasker

4

4

GB/T 91–3.2x16–A0P

Split pin

4

5

TB504.433–09

Retraction spring

2

6

TB504.433–07

Pull rod

2

7

GB/T 6170–M10–LH–A3L

Type 1 kex nut

2

8

FT300.43.110

Pull rod rear fork

2

9

GB/T 894.1–25

Circlip for skaft

1

10

GB/T 97.1–24–A0P

Flat wasker

1

11

FT300.43.130

Pedal retraction spring

2

12

TB504.433.3

Rigkt brake pedal body unit

1

13

TB504.433.10

Rigkt brake pedal body weldment

1

14

GB/T 879.1–6x40

Spring column pin

1

15

GB/T 879.1–10x40

Spring column pin

1

16

FT300.43.020a

Pedal skaft unit

1

17

GB/T 5873–M6x16–8.8–A2L

Hex bolt

2

18

GB/T 93–6–A0P

Standard spring wasker

2

19

TB504.433.1

Left brake pedal unit

1

20

TB504.433.2

Left brake pedal weldment

1
