TD800.454E 45.4-操纵盖板总成 45.4-CONTROLLING COVER PLATE ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

2

3

4

GBT818-M5X16-A2L GBT93-5-AOP GBT97.1-5-AOP FT804A.45.097

SCREW WASHER WASHER

COVER PLATE COMBINATION

4

4

4

1

2013-04_

2011-11_

2011-11_

2011-11_








TD800.456A 45.6-仪表台装配总成 45.6-DASHBOARD INSTALLATION ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

2

3

4

4

FT800A.45B.020 FT65.45.999

GBT901-M6X60-A1L FT800A.45.900 GBT818

DASHBOARD ASSEMBLY NUT

STUD

PLASTIC SCREW SCREW M4X16

1

2

2

6

6

2011-11_

2011-11_

2011-11_

2004-01_

2010-06_








TD800.457 45.7-前连接装置总成 45.7-FRONT CONNECTION EQUIPMENT ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

2

3

4

5



6

7

8

9

TD800.457-01 FT800A.45.112 FT800A.45.110 FT800A.45.111 GBT96-16-A0P



GBT5782-M16X130-A2L GBT5783-M16X45 GBT97.1-16-A0P GBT93-16-A0P

FRONT CONNECTING PLATE SHOCK ABSORBER SEAT ABSORBER

SPACER SPOOL WASHER



BOLT BOLT WASHER

SPRING WASHER

2

8

8

4

4



4

8

8

8

2011-11_

2011-11_

2011-11_

2011-11_

2011-11_



2011-11_



2011-11_

2011-11_








TD800.458A 45.8-后连接装置总成 45.8–REAR CONNECTING EQUIPMENT ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

GBT5782-M16X160-A2L

BOLT

4

2011-11_

10

GBT6170-M16-A3L

NUT M16-A3L

8

2011-11_

2

GBT93-16-A0P

SPRING WASHER

8

2011-11_

3

GBT96.1-16-A0P

WASHER

8

2011-11_

4

FT800A.45.112

SHOCK ABSORBER SEAT

8

2011-11_

5

FT800A.45.110

ABSORBER

8

2004-01_

5

TD800.457B.1.2

ABSORBER

8

2009-06_

5

TD800.457B.1.2

ABSORBER

8

2009-06_

6

FT800A.45.111

SPACER SPOOL

4

2011-11_

7

FT800A.45C.014

FLOOR REAR CONNECTING WELDMENT

2

2011-11_

8

GBT5783-M16X90-8.8-A2L

BOLT

4

2004-01_

9

GBT97.1-16-A0P

WASHER

4

2011-11_








FT800A.46.001 46-安全架总成 46-SAFETY FRAME ASSEMBLY



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

GBT5783-M10X30-A3L

BOLT

6

2011-11_

10

GBT802-M12-A2L

NUT

4



11

FT800A.46.040

SUPPORT BEAM INSTALLATION ASSEMBLY

1

2011-11_

11

FT800A.46.040

SUPPORT BEAM INSTALLATION ASSEMBLY

1

2011-11_

11.1

FT800A.46.010

SAFETY FRAME UPPER BEAM ASSEMBLY

1

2011-11_

11.1

FT800A.46.010

SAFETY FRAME UPPER BEAM ASSEMBLY

1

2011-11_

11.2

GBT5782-M16X100-A2L

BOLT

6

2011-11_

11.3

GBT95-16-A0P

WASHER

6

2011-11_

11.4

GBT93-16-A0P

SPRING WASHER

6

2011-11_

11.5

GBT802-M16

NUT

6



11.6

FT800A.46.030

RIGHT SUPPORT BEAM ASSEMBLY

1

2011-11_

11.7

FT800A.46.020

LEFT SUPPORT BEAM ASSEMBLY

1

2011-11_

12

GBT5782-M16X90-A2L

BOLT

8

2011-11_

13

GBT96-16-A0P

WASHER

8

2011-11_

14

GBT93-16-A0P

SPRING WASHER

8

2011-11_

15

GBT6170-M16-A3L

NUT M16-A3L

8

2011-11_

2

FT800A.46.101

SHADOW LOCKING PLATE

2

2011-11_

3

FT400.46.021

WASHER UNIT

6

2011-11_

4

GBT93-10-A0P

WASHER

6

2011-11_

5

GBT802-M10-6

NUT

6

2011-11_

6

FT65.46A.012

SHADOW ASSEMBLY

1

2004-01_

6

FT800A.46.480

SHADOW

1

2011-05_

7

GBT5782-M12x80-A2L

BOLT

4

2011-11_

8

GBT95-12-A0P

WASHER

4

2011-11_

9

GBT93-12-A0P

SPRING WASHER

4

2011-11_








TD800.471-1 47.1.1-机罩总成-1 BONNET ASSEMBLY-1



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

1

FT65.47.110

REAR SEAL RUBBER STRIP

1

2011-11_

10

FT800A.47.060

BONNET LOWER BRACKET

1

2011-11_

11

GBT5783-M12X30-A3L

BOLT

5



12

GBT5783-M12X45-A3L

BOLT

4



13

GBT6187-M16-A3L

HEXAGON LOCKING NUT、 TYPE 1

2

2011-11_

13

GBT6187-M16-A3L

HEXAGON LOCKING NUT、 TYPE 1

2

2011-11_

14

FT800.47.205

BONNET UPPER BRACKET

1

2011-11_

15

GBT5783-M16X100－A2L

BOLT

2

2011-11_

16

FT65.47.193

CONNECTING ROD BRACKET-LEFT

1

2011-11_

17

GBT5783-M8X20-A2L

BOLT

4



18

GBT97.1-8-A0P

WASHER

6

2011-11_

19

GBT93-8-A0P

WASHER

6

2011-11_

2

FT800A.47.010

ENGINE BONNET UPPER PLATE WELDMENT ASSEMBLY

1

2011-11_

20

GBT6170-M8-A2L

NUT

7

2011-11_

21

FT65.47.192

CONNECTING ROD BRACKET-RIGHT

1

2011-11_

22

TD800.471.2

RIGHT REAR CONNECTING ROD WELDMENT

1

2011-11_

23

TD800.471-01

BONNET PNEUMATIC SPRING

2

2011-11_

24

TD800.471.1

LEFT REAR CONNECTING ROD WELDMENT

1

2011-11_

25

GBT5783-M12X35-A3L

BOLT

3



25

GBT5783-M12X35-A3L

BOLT

3



26

GBT97.1-12-A0P

WASHER

14

2011-11_

3

GBT5783-M6X12-A2L

BOLT

20



4

FT65.48.097

HARNESS LOCKING CLAMP (2)

8

2011-11_

5

GBT93-6-A0P

SPRING WASHER

22

2011-11_

6

GBT6170-M6-A2L

NUT

24

2011-11_








TD800.471-1 47.1.1-机罩总成-1(续)



标号 No.

代号 Code

名称 Description

数量 Quantity

备注 Remark

7

8

9

FT800.47.011b GBT6170-M12-A3L GBT93-12-A0P

ENGINE BONNET FRONT BOARD ASSEMBLY NUT

SPRING WASHER

1

10

13

2011-11_

2011-11_

2011-11_
