LOVOL TC2A454-006K Tractor Parts Catalogue 21
FT300.74B.001 74-前配重架总成 74-FRONT BALLAST BRACKET ASSEMBLY
|
标号 No. |
代号 Code |
名称 Description |
数量 Quantity |
备注 Remark |
|
|
1 |
FT300.74B.102 |
前配重架垫块 |
FRONT BALLAST BRACKET MAT BLOCK |
1 |
2011-11_ |
|
2 |
FT300.74B.101 |
配重架 |
BALLAST BRACKET |
1 |
2009-11_ |
|
2 |
FT300.74A.101 |
配重架 |
BALLAST BRACKET |
1 |
2004-01_ |
|
3 |
GBT898-AM16-M16X70-Zn.D |
双头螺柱 |
8.8-A3L STUD |
4 |
2011-11_ |
|
4 |
GBT97.1-16 |
垫圈 |
WASHER |
6 |
2011-11_ |
|
5 |
GBT93-16-Zn.D |
标准型弹簧垫圈 |
WASHER |
6 |
2011-11_ |
|
6 |
GBT6170-M16-A3L |
螺母M16-A3L |
NUT M16-A3L |
4 |
|
|
7 |
GBT5780-M16X90-A2L |
六角头螺栓 |
BOLT |
2 |
|
TB400.91 91-后配重总成 91-REAR BALLAST ASSEMBLY
|
标号 No. |
代号 Code |
名称 Description |
数量 Quantity |
备注 Remark |
|
|
1 |
GBT6171-M16X1.5-A3L |
1型六角螺母 |
NUT |
3 |
2011-11_ |
|
2 |
GBT93-16-A0P |
弹簧垫圈 |
SPRING WASHER |
6 |
2011-11_ |
|
3 |
TB400.91-02 |
后配重螺钉Ⅰ |
REAR BALLAST SCREW I |
3 |
2011-11_ |
|
4 |
TB400.91-01 |
后配重 |
REAR BALLAST |
6 |
2011-11_ |
|
5 |
TB400.91-04 |
垫圈 |
WASHER |
18 |
2004-01_ |
|
5 |
FT650.34.104 |
垫圈 |
WASHER |
18 |
2009-09_ |
|
6 |
TB400.91-03 |
后配重螺钉Ⅱ |
REAR BALLAST SCREW Ⅱ |
15 |
2011-11_ |
|
6 |
TB400.91-03 |
后配重螺钉Ⅱ |
REAR BALLAST SCREW Ⅱ |
15 |
2011-11_ |
|
7 |
TB400.91-05 |
螺栓 |
BOLT |
3 |
2011-11_ |
