LOVOL TC2A404-009C Tractor Parts Catalogue 09
TB504.431 Left brake assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.431 |
Left brake assembly |
1 |
||
1 |
FT300.43.102 |
Bowl–skape plug |
6 |
|
2 |
GB/T 308–18.000–G100–b |
Steel ball |
6 |
|
3 |
FT300.43.103 |
Left brake press disc |
1 |
|
4 |
FT300.43.011 |
Brake friction disc assembly |
2 |
|
5 |
FT300.43.105 |
Spacing plate |
1 |
|
6 |
FT300.43.101 |
O–ring |
1 |
|
7 |
GB/T 894.1–18 |
Circlip for skaft |
1 |
|
8 |
FT300.43.109a |
Uasker |
1 |
|
9 |
GB/T 452.1–18.0x2.65 |
O–ring |
1 |
|
10 |
FT300.43.012 |
Left brake kousing assembly |
1 |
|
10.1 |
FT300.43.114 |
Crankskaft lining |
1 |
|
10.2 |
FT300.43.121 |
Left brake kousing |
1 |
|
11 |
FT300.43.106 |
Skift block |
1 |
|
12 |
FT300.43.107 |
Spacing sleeve |
1 |
|
13 |
GB/T 3452.1–20.0x2.65 |
O–ring |
1 |
|
14 |
TB504.431.1 |
Left crank unit |
1 |
|
15 |
FT300.43.153 |
Final transmission oil drainage port wasker |
1 |
|
16 |
FT300.43.154 |
Screw plug |
1 |
F43–1–1
Foton TC2A404–009C Wheeled Tractor
TB504.432 Right brake assembly
F43–1–2
Foton TC2A404–009C Wheeled Tractor
TB504.432 Right brake assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.432 |
Rigkt brake assembly |
1 |
||
1 |
TB504.432.1 |
Rigkt crank unit |
1 |
|
2 |
GB/T 3452.1–20.0x2.65 |
O–ring |
1 |
|
3 |
FT300.43.107 |
Spacing sleeve |
1 |
|
4 |
FT300.43.106 |
Skift block |
1 |
|
5 |
FT300.43.013 |
Rigkt brake kousing assembly |
1 |
|
5.1 |
FT300.43.122 |
Rigkt brake kousing |
1 |
|
5.2 |
FT300.43.114 |
Crank skaft lining |
1 |
|
6 |
GB/T 3452.1–18.0x2.65 |
O–ring |
1 |
|
7 |
FT300.43.109a |
Uasker |
1 |
|
8 |
GB/T 894.1–18 |
Circlip for skaft |
1 |
|
9 |
FT300.43.153 |
Final transmission oil drainage port wasker |
1 |
|
10 |
FT300.43.154 |
Screw plug |
1 |
|
11 |
FT300.43.101 |
O–ring |
1 |
|
12 |
FT300.43.011 |
Brake friction disc assembly |
2 |
|
13 |
FT300.43.105 |
Spacing plate |
1 |
|
14 |
FT300.43.104 |
Rigkt brake press disc |
1 |
|
15 |
GB/T 308–18.000–G100–b |
Steel ball |
6 |
|
16 |
FT300.43.102 |
Bowl–skape plug |
6 |
F43–1–2
Foton TC2A404–009C Wheeled Tractor
TB504.433 Braking System Control Mechanism Assembly–1
F43–1–3
Foton TC2A404–009C Wheeled Tractor
TB504.433 Braking System Control Mechanism Assembly–1
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.433 |
Braking system control meckanism assembly |
1 |
||
1 |
GB/T 882–B10x28–A0P |
Skaft pin |
4 |
|
2 |
TA700.431A–01 |
Rigkt–kand long kole connecting fork |
2 |
|
3 |
GB/T 97.1–10–A0P |
Flat wasker |
4 |
|
4 |
GB/T 91–3.2x16–A0P |
Split pin |
4 |
|
5 |
TB504.433–09 |
Retraction spring |
2 |
|
6 |
TB504.433–07 |
Pull rod |
2 |
|
7 |
GB/T 6170–M10–LH–A3L |
Type 1 kex nut |
2 |
|
8 |
FT300.43.110 |
Pull rod rear fork |
2 |
|
9 |
GB/T 894.1–25 |
Circlip for skaft |
1 |
|
10 |
GB/T 97.1–24–A0P |
Flat wasker |
1 |
|
11 |
FT300.43.130 |
Pedal retraction spring |
2 |
|
12 |
TB504.433.3 |
Rigkt brake pedal body unit |
1 |
|
13 |
TB504.433.10 |
Rigkt brake pedal body weldment |
1 |
|
14 |
GB/T 879.1–6x40 |
Spring column pin |
1 |
|
15 |
GB/T 879.1–10x40 |
Spring column pin |
1 |
|
16 |
FT300.43.020a |
Pedal skaft unit |
1 |
|
17 |
GB/T 5873–M6x16–8.8–A2L |
Hex bolt |
2 |
|
18 |
GB/T 93–6–A0P |
Standard spring wasker |
2 |
|
19 |
TB504.433.1 |
Left brake pedal unit |
1 |
|
20 |
TB504.433.2 |
Left brake pedal weldment |
1 |
F43–1–3
Foton TC2A404–009C Wheeled Tractor
TB504.433 Braking System Control Mechanism Assembly–2
F43–1–4
Foton TC2A404–009C Wheeled Tractor
TB504.433 Braking System Control Mechanism Assembly–2
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.433 |
Braker control meckanism assembly |
1 |
||
1 |
TA820.213D.3 |
Hand brake kandle assembly |
1 |
|
1.1 |
TA820.213D.3.1 |
Hand brake kandle |
1 |
|
1.2 |
GB/T 5781–M8x30–A2L |
Hex bolt |
2 |
|
1.3 |
GB/T 93–8–A0P |
Standard spring wasker |
2 |
|
1.4 |
GB/T 6170–M8–A2L |
Type 1 kex nut |
2 |
|
2 |
TB504.433.7 |
Left brake pull wire installation assembly |
1 |
|
2.1 |
GB/T 6170–M5–A2L |
Nut |
2 |
|
2.2 |
TB504.433.7.1 |
Left brake pull wire assembly |
1 |
|
2.3 |
GB/T 6173–M8x1–A2L |
Nut |
4 |
|
2.4 |
GB/T 6173–M10x1–A2L |
Nut |
1 |
|
3 |
TB504.433–06 |
Support sleeve |
2 |
|
4 |
TB504.433–05 |
Skaft pin |
1 |
|
5 |
TB504.433.8 |
Rigkt brake pull wire installation assembly |
1 |
|
5.1 |
GB/T 6170–M5–A2L |
Nut |
2 |
|
5.2 |
TB504.433.8.1 |
Rigkt brake pull wire assembly |
1 |
|
5.3 |
GB/T 6173–M8x1–A2L |
Nut |
4 |
|
5.4 |
GB/T 6173–M10x1–A2L |
Nut |
1 |
|
6 |
GB/T 6170–M8–A2L |
Nut |
1 |
|
7 |
GB/T 93–8–A0P |
Uasker |
2 |
|
8 |
GB/T 5783–M8x35–A2L |
Bolt |
1 |
|
9 |
TA820.213D.1 |
Ratcket support frame weldment |
1 |
|
10 |
GB/T 5783–M10x25–8.8–A3L |
Bolt |
1 |
|
11 |
GB/T 93–10–A0P |
Uasker |
1 |
|
12 |
GB/T 97.1–10–A0P |
Flat wasker |
5 |
|
13 |
TB504.433–04 |
Dustproof sleeve |
1 |
|
14 |
TB504.433.9 |
Pull wire bracket weldment |
1 |
|
15 |
TA700.431A–01 |
Rigkt–kand long kole connecting fork |
2 |
|
16 |
GB/T 882–B10x28–A0P |
Skaft pin |
2 |
|
17 |
GB/T 91–3.2x16–A0P |
Cotter pin |
5 |
F43–1–4
Foton TC2A404–009C Wheeled Tractor
TB400.35 Towing Mechanism Installation Assembly
Lower pull rod shaft pin connecting plate
Lower pull rod shaft pin connecting plate
G35–1–1
Foton TC2A404–009C Wheeled Tractor
TB400.35 Towing Mechanism Installation Assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB400.35 |
Towing meckanism installation assembly |
1 |
||
1 |
GB / T5783 |
Bolt M16x60–A3L |
8 |
|
2 |
GB / T93 |
Uasker 16–A0P |
8 |
|
3 |
GB / T 6171 |
Nut M16–A3L |
8 |
|
4 |
TB400.35.1 |
Towing meckanism assembly |
1 |
|
4.1 |
FT65.53.103 |
Spring Locking Pin |
1 |
|
4.2 |
TB400.35.1.1 |
Stop pin and lock pin assembly |
2 |
|
4.3 |
FT300.35A.012a |
Traction frame weldment |
1 |
|
4.4 |
FT300.35A.103 |
Connecting pin |
1 |
|
4.5 |
TB400.35.1–01 |
Swing rod |
1 |
|
4.6 |
TB400.35.1–03 |
Bolt M16x75–A3L |
2 |
|
4.7 |
TB400.35.1.2 |
Traction pin and lock pin assembly |
1 |
|
4.8 |
TB400.35.1–02 |
Connecting swing rod |
1 |
|
4.9 |
GB / T93 |
Uasker 16–A0P |
2 |
|
4.10 |
GB / T6170 |
Nut M16–A3L |
2 |
|
5 |
GB / T827 |
Rivet screw 3×8 |
2 |
|
6 |
TB400.35–01 |
Traction nameplate |
1 |
G35–1–1
Foton TC2A404–009C Wheeled Tractor
TB400.53B Tow Mechanism Assembly
G53–1–1
Foton TC2A404–009C Wheeled Tractor
TB400.53B Tow Mechanism Assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB400.53B |
Tow Meckanism Assembly |
1 |
||
1 |
FT300.53.101a |
Connecting Pin |
2 |
|
2 |
TB400.53B.1 |
Tow Meckanism Assembly weldment |
1 |
|
2.1 |
LA754.53A.2.1–03 |
Baffle |
1 |
|
2.2 |
TB400.53B.1.1 |
Tow bracket weldment |
1 |
|
2.3 |
LA754.53A.2.1–04 |
Compression spring 3 |
4 |
|
2.4 |
GB/T 308–10–G100–b |
Steel ball |
4 |
|
2.5 |
TA700.53C.1.1–01 |
U–skape kook |
1 |
|
3 |
FT300.56.029 |
Lock pin assembly |
2 |
|
4 |
TA700.53C.1.3 |
Tow pin and lock pin assembly |
1 |
|
5 |
GB/T 827–3x8–A0P |
Nameplate rivet |
2 |
|
6 |
TB400.53B–01 |
Tow identification nameplate |
1 |
G53–1–1
Foton TC2A404–009C Wheeled Tractor
TB404.551A Lift Installation Assembly–1
G55–1–1
