LOVOL TB604-Q161Y2K Tractor Parts Catalogue 16
TB450.487E Instrument Installation Assembly
No. |
Part code and specification |
Part name |
Quantity |
Remark |
TB450.487E |
Instrument installation assembly |
1 |
||
1 |
GB/T 818-M5X25-4.8-A2L |
Cross recessed pan head screw |
3 |
|
2 |
TB450.487E.1 |
Compound instrument assembly |
1 |
|
3 |
GB/T 95-5-AOP |
Flat washer |
3 |
|
4 |
GB/T 93-5-AOP |
Standard spring washer |
3 |
|
5 |
GBT 6170-M5-8-A2L |
Type 1 hex nut |
3 |
|
6 |
TB450.487E.2 |
Transit harness assembly |
1 |
175
Foton TB604-Q161Y2K Wheeled Tractor
TB450.489A Preheating device assembly
176
Foton TB604-Q161Y2K Wheeled Tractor
TB450.489A Preheating device assembly
No. |
Part code and specification |
Part name |
Quantity |
Remark |
1 |
TB450.489A FT300.48.027 |
Preheating device assembly Preheating wire 1 |
1 1 |
177
