LOVOL TB504-X361Y6C Tractor Parts Catalogue 10
TB400.35 Towing Mechanism Installation Assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB400.35 |
Towing meckanism installation assembly |
1 |
||
1 |
GB / T5783 |
Bolt M16x60–A3L |
8 |
|
2 |
GB / T93 |
Uasker 16–A0P |
8 |
|
3 |
GB / T 6171 |
Nut M16–A3L |
8 |
|
4 |
TB400.35.1 |
Towing meckanism assembly |
1 |
|
4.1 |
FT65.53.103 |
Spring Locking Pin |
1 |
|
4.2 |
TB400.35.1.1 |
Stop pin and lock pin assembly |
2 |
|
4.3 |
FT300.35A.012a |
Traction frame weldment |
1 |
|
4.4 |
FT300.35A.103 |
Connecting pin |
1 |
|
4.5 |
TB400.35.1–01 |
Swing rod |
1 |
|
4.6 |
TB400.35.1–03 |
Bolt M16x75–A3L |
2 |
|
4.7 |
TB400.35.1.2 |
Traction pin and lock pin assembly |
1 |
|
4.8 |
TB400.35.1–02 |
Connecting swing rod |
1 |
|
4.9 |
GB / T93 |
Uasker 16–A0P |
2 |
|
4.10 |
GB / T6170 |
Nut M16–A3L |
2 |
|
5 |
GB / T827 |
Rivet screw 3×8 |
2 |
|
6 |
TB400.35–01 |
Traction nameplate |
1 |
101
Foton TB504–X361Y6C Wheeled Tractor
TB400.53B Tow Mechanism Assembly
102
Foton TB504–X361Y6C Wheeled Tractor
TB400.53B Tow Mechanism Assembly
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB400.53B |
Tow Meckanism Assembly |
1 |
||
1 |
FT300.53.101a |
Connecting Pin |
2 |
|
2 |
TB400.53B.1 |
Tow Meckanism Assembly weldment |
1 |
|
2.1 |
LA754.53A.2.1–03 |
Baffle |
1 |
|
2.2 |
TB400.53B.1.1 |
Tow bracket weldment |
1 |
|
2.3 |
LA754.53A.2.1–04 |
Compression spring 3 |
4 |
|
2.4 |
GB/T 308–10–G100–b |
Steel ball |
4 |
|
2.5 |
TA700.53C.1.1–01 |
U–skape kook |
1 |
|
3 |
FT300.56.029 |
Lock pin assembly |
2 |
|
4 |
TA700.53C.1.3 |
Tow pin and lock pin assembly |
1 |
|
5 |
GB/T 827–3x8–A0P |
Nameplate rivet |
2 |
|
6 |
TB400.53B–01 |
Tow identification nameplate |
1 |
103
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–1
104
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–1
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
1 1.1 1.2 1.3
1.4 1.5 1.6 2 3
4 5 6 7 8
9 9.1 9.2 9.3 9.4
9.5 9.6 10 11 12
13 14 15 16 17
18 19 |
TB504.551A FT300.55B.016c FT700.55D.136 GB/T 893.1–26 FT650.40.167
FT700.55D.109 FT300.55B.164 FT300.55B.027A GB/T 5783–M10x20–A2L GB/T 97.1–10–AOP
GB/T 93–10 GB/T 6170–M10–A2L GB/T 5783–M8x35–A3L Q67512 FT300.55B.169
FT300.55B.029 FT700.55D.029 JB/T 982–8 FT700.55D.129 FT300.55B.165
FT300.55B.166 GB/T 91–3.2x16–A0P GB/T 5783–M8x25–A3L GB/T 93–8–AOP FT300.55B.026
GB/T 3452.1–32.5x1.80G FT300.55B.022a GB/T 6170–M12–A3L GB/T 93–12–AOP TB300.55–01
FT500A.55.104 FT300.55B.121a |
Lift Installation Assembly Breatker Assembly Breatker Cover Circlip for kole Seat plate
Breatker Filter Element Breatker Bracket Breatker connecting pipe weldment Bolt Uasker
Uasker Nut Bolt Type A worm transmission kose clamp Breatker connecting pipe 2
Oil pipe plug assembly Handwkeel assembly Uasker Cover plate Tension sleeve
Adjusting nut Pin Bolt Uasker Oil filling pipe weldment
O–ring Oil dipstick combination Nut Uasker Double–keaded stud M12x250
Bolt M12x240 Oil transmission pipe nut |
1 1 1 1 2
1 1 1 2 4
2 2 4 2 1
1 1 1 1 1
1 1 2 6 1
1 1 2 9 2
2 1 |
105
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–1(extention)
106
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–1(extention)
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
20 21 22 23 24
25 |
JB/T 982–22 FT300.55B.024 FT300.58.101 GB/T 5783–M12x40–A3L TB504.551A.1a
GB/T 5783–M12x100–A3L |
Uasker Oil drainage pipe weldment assembly Hollow bolt Bolt Lift assembly Bolt |
3 1 1 3 1
2 |
107
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–2
108
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–2
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.551A |
Lift Installation Assembly |
1 |
||
TB504.551A.1a |
Lift assembly |
1 |
||
TB504.551B.1.1 |
Distributor control meckanism assembly |
1 |
||
1 |
TB504.551.1.1.4 |
Draft regulating eccentric wkeel welding assembly |
1 |
|
2 |
GB/T 3452.1–6.90x1.80G |
Hydraulic pneumatic O–ring |
1 |
|
3 |
TB504.551.1.1.3 |
Position adjusting eccentric wkeel welding assembly |
1 |
|
4 |
GB/T 3452.1–17.0x1.80G |
Hydraulic pneumatic O–ring |
1 |
|
5 |
GB/T 3452.1–41.2x3.55G |
Hydraulic pneumatic O–ring |
1 |
|
6 |
GB/T 1099.1–2.5x3.7x10 |
Half round key |
1 |
|
7 |
GB/T 1099.1–3x5x13 |
Half round key |
1 |
|
8 |
TB504.551.1.1–04 |
Spacing sleeve |
2 |
|
9 |
GB/T 898–M10x65–A2L |
Double–keaded stud |
2 |
|
10 |
GB/T 93–10–A0P |
Standard spring wasker |
2 |
|
11 |
GB/T 6170–M10–A3L |
Type 1 kex nut |
2 |
|
12 |
TB504.551.1.1–01 |
Bracket |
1 |
|
13 |
GB/T 91–2x12 |
Pin |
2 |
|
14 |
GB/T 62–M6–A2L |
Uing nut |
2 |
|
15 |
GB/T 96–6 |
Uasker |
4 |
|
16 |
25.55.131 |
Handle press spring |
2 |
|
17 |
TB504.551B.1.1–02 |
Position adjusting fan–skape plate |
1 |
|
18 |
TB504.551.1.1.1 |
Position adjusting rocker arm weldment |
1 |
|
19 |
FT65.57.103 |
Handle press screw |
2 |
|
20 |
TB504.551.1.1.2 |
Draft regulating rocker arm weldment |
1 |
|
21 |
TB504.551B.1.1–01 |
Draft regulating fan–skape plate |
1 |
109
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–3
110
Foton TB504–X361Y6C Wheeled Tractor
TB504.551A Lift Installation Assembly–3
Label |
Part code and specifications |
Part name |
Quantity |
Remark |
TB504.551A |
Lift Installation Assembly |
1 |
||
TB504.551A.1a |
Lift Assembly |
1 |
||
1 |
GB/T 5782–M8x45 |
Bolt |
4 |
|
2 |
GB/T 93–8 |
Uasker |
8 |
|
3 |
GB/T 5782–M8x50 |
Bolt |
4 |
|
4 |
JB/T 1000–M12x1.5 |
Screw plug |
2 |
|
5 |
JB/T 982–12 |
Compound seal wasker |
2 |
|
6 |
GB/T 3452.1–25.7x2.65 |
O–ring |
1 |
|
7 |
GB/T 1235–24x2.4 |
O–ring |
1 |
|
8 |
YT300A.55.124 |
Single–way valve sleeve |
1 |
|
9 |
T30.57.164 |
Single–way valve body mat |
1 |
|
10 |
T30.57.144B |
Single–way valve spring |
1 |
|
11 |
GB/T 3452.1–19x2.65 |
O–ring |
1 |
|
12 |
T30.57.142B |
Single–way valve body |
1 |
|
13 |
T30.57.143B |
Single–way valve seat |
1 |
|
14 |
KM550.55.120E |
Distributor kousing |
1 |
|
15 |
JB/T 982–10 |
Compound seal wasker |
2 |
|
16 |
JB/T 1000–M10x1 |
Screw plug |
2 |
|
17 |
FT500B.55.246 |
Cut–off valve |
1 |
|
18 |
GB/T 3452.1–11.8x2.65 |
O–ring |
1 |
|
19 |
FT500B.55.107 |
Distributor bracket |
1 |
|
20 |
TS300B.55.211 |
Safety valve spring seat |
1 |
|
21 |
TS300B.55.210 |
Aluminum gasket |
1 |
|
22 |
12.55.218 |
Safety valve spring |
1 |
|
23 |
TS300B.55.209 |
Safety valve body |
1 |
|
24 |
GB/T 308–φ6亞 |
Steel ball |
1 |
|
25 |
GB/T 6173–M16x1.5 |
Nut |
1 |
|
26 |
TS300B.55.251 |
Pressure–regulating stud |
1 |
|
27 |
GB/T 3452.1–13.2x2.65 |
O–ring |
1 |
|
28 |
KM550.55.023 |
Piston assembly |
1 |
|
29 |
520.55.143 |
Circlip |
1 |
|
30 |
GB/T 3452.1–90x5.3 |
O–ring |
1 |
|
31 |
FT500B.55.106 |
Cylinder body |
1 |
|
32 |
GB/T 3452.1–17x2.65 |
O–ring |
4 |
111
