LOVOL FT254 TL1A254-001K Tractor Parts Catalogue 21
FT250.74.001 74-前配重总成 74-FRONT BALLAST ASSEMBLY
|
标号 No. |
代号 Code |
名称 Description |
数量 Quantity |
备注 Remark |
|
|
1 2 3 4 5 |
FT250.74.102 FT250.74.101a GBT97.1-12-A0P GBT93-12-A0P GBT6170-M12-A3L |
配重固定螺栓前配重 平垫圈垫圈 螺母 |
BALLAST FIXING BOLT FRONT BALLAST WASHER WASHER NUT |
1 6 2 1 1 |
2011-11_ 2006-12_ 2011-11_ 2011-11_ 2011-11_ |
FT250.91B.001 91-后配重总成 91-REAR BALLAST ASSEMBLY
|
标号 No. |
代号 Code |
名称 Description |
数量 Quantity |
备注 Remark |
|
|
1 |
GBT5783-M16X1.5X35-A3L |
六角头螺栓 |
BOLT |
3 |
2011-11_ |
|
1 |
GBT5783-M16X30-8.8-A3L |
六角头螺栓 |
BOLT |
3 |
2004-01_ |
|
1 |
TE350.91-04 |
螺栓 |
BOLT |
3 |
2011-11_ |
|
2 |
FT650.34.104 |
垫圈 |
WASHER |
6 |
2011-11_ |
|
3 |
FT250.91B.101 |
后配重 |
REAR BALLAST |
2 |
2011-11_ |
|
4 |
FT250.91B.103 |
配重螺钉Ⅱ |
BALLAST SCREW II |
3 |
2011-11_ |
|
5 |
FT250.91B.102 |
配重螺钉Ⅰ |
BALLAST SCREW I |
3 |
2011-11_ |
|
6 |
GBT6171-M16X1.5-A3L |
1型六角螺母 |
NUT |
3 |
2011-11_ |
TL01482090000K 车身线束安装总成 BODY HARNESS INSTALLATION ASSEMBLY
|
标号 No. |
代号 Code |
名称 Description |
数量 Quantity |
备注 Remark |
|
|
1 |
TE250.482X.1 |
机罩气弹簧 |
BONNET PNEUMATIC SPRING |
1 |
2014-06_ |
|
10 |
GBT93-5-A0P |
标准型弹簧垫圈 |
WASHER |
2 |
2014-06_ |
|
11 |
TB450.482.2 |
启动继电器 |
STARTING RELAY |
1 |
2014-06_ |
|
12 |
TE250.482A.3 |
电压调节器 |
VOLTAGE ADJUSTER |
1 |
2014-06_ |
|
13 |
GBT97.1-6-A0P |
平垫圈 |
WASHER |
4 |
2014-06_ |
|
14 |
GBT93-6-A0P |
垫圈 |
WASHER |
4 |
2014-06_ |
|
15 |
GBT6170-M6-8-A2L |
1型六角螺母 |
NUT |
3 |
2014-06_ |
|
16 |
TL01482010001K |
龙门架左下支架焊合 |
1 |
2014-06_ |
|
|
17 |
TH354.482.5 |
右翘板开关 |
RIGHT BUTTON SWITCH |
1 |
2014-06_ |
|
18 |
FT300.48.064 |
点火锁 |
IGNITION LOCK |
1 |
2014-06_ |
|
19 |
TH354.482.4 |
左翘板开关 |
LEFT PADDLE SWITCH |
1 |
2014-06_ |
|
2 |
Q67405100 |
塑料紧箍带 |
PLASTIC FASTEN STRIP |
2 |
2014-06_ |
|
20 |
GBT5783-M5X20-8.8-A2L |
六角头螺栓 |
BOLT |
2 |
2014-06_ |
|
3 |
GBT818-M4X10-4.8-A2L |
十字槽盘头螺钉 |
SCREW |
5 |
2014-06_ |
|
4 |
GBT93-4-A0P |
标准型弹簧垫圈 |
WASHER |
5 |
2014-06_ |
|
5 |
TB400.484A.2 |
油量传感器 |
OIL QUANTITY SENSOR |
1 |
2014-06_ |
|
6 |
GBT818-M6X25-4.8-A2L |
十字槽盘头螺钉 |
SCREW |
4 |
2014-06_ |
|
7 |
TE250.482A-02 |
继电器盒盖 |
RELAY BOX COVER |
1 |
2014-06_ |
|
8 |
TE250.482A.2 |
继电器盒总成 |
RELAY BOX ASSEMBLY |
1 |
2014-06_ |
|
9 |
GBT97.1-5-A0P |
垫圈 |
WASHER |
2 |
2014-06_ |
