4TNE98 YANMAR PARTS FOR FORKLIFT
| 729903-01560 | BLOCK ASSY, CYLINDER |
| 23876-030000 | PLUG PT3/8,SCREW |
| 171051-01921 | PLUG |
| 129900-02020 | BOLT, METAL CAP |
| 129900-02410 | BUSH, CAMSHAFT |
| 22190-080002 | SEAL WASHER 8S |
| 22351-060012 | SPRING PIN 6X12 |
| 23876-030000 | PLUG PT3/8,SCREW |
| 26106-080122 | BOLT M 8X 12 PLATED |
| 129900-01250 | PLUG 55 |
| 23876-030000 | PLUG PT3/8,SCREW |
| 27241-300000 | PLUG 30 |
| 129900-02931 | BEARING ASSY, THRUST |
| 729900-02801 | MAIN BEARING SET |
| 129900-01200 | BOLT, HEAD |
| 129903-01350 | GASKET, HEAD |
| 129900-02341 | MAIN BEARING US=0.25 |
| 129900-02941 | BEARING,THRUST .25OS |
| 129917-01500 | GEARCASE COVER CMP |
| 129916-01800 | SEAL, OIL |
| 129951-01740 | COVER, F.I. PUMP |
| 24341-000500 | O-RING 1A S-50.0 |
| 124160-01751 | COVER,FILLER |
| 24311-000320 | O-RING 1A P-32.0 |
| 129970-01500 | HOUSING, GEAR |
| 129900-32001 | PUMP ASSY, LUB.OIL |
| 129900-26250 | BALL BEARING |
| 26226-080302 | STUD M 8X 30 PLATED |
| 121023-26070 | COVER, HO-P |
| 24321-000850 | O-RING 1A G-85.0 |
| 129900-32030 | O-RING P20 |
| 129900-32040 | O-RING P14 |
| 129100-01580 | PARALLEL PIN 8X16 |
| 129900-14140 | BEARING #6205 |
| 129900-26250 | BALL BEARING |
| 26106-080162 | BOLT M 8X 16 PLATED |
| 26106-080202 | BOLT M 8X 20 PLATED |
| 26106-080302 | BOLT M 8X 30 PLATED |
| 26106-080402 | BOLT M 8X 40 PLATED |
| 26106-080402 | BOLT M 8X 40 PLATED |
| 26106-080452 | BOLT M 8X 45 PLATED |
| 129001-91810 | BOLT M 8X 70 PLATED |
| 129001-91810 | BOLT M 8X 70 PLATED |
| 26106-100122 | BOLT M10X 12 PLATED |
| 26306-080002 | NUT |
| PARTS NO. | DESCRIPTION |
| 129100-01580 | PARALLEL PIN 8X16 |
| 129906-01610 | HOUSING, FLYWHEEL |
| 26206-100352 | BOLT M10X 35 PLATED |
| 26206-100202 | BOLT M10X20 |
| 129916-01790 | SEAL, OIL |
| 129930-01710 | SUMP ASSY, OIL |
| 119640-01640 | DRAIN PLUG M22 |
| 22190-220002 | SEAL WASHER 22S |
| 26106-080122 | BOLT M 8X 12 PLATED |
| 22312-120200 | PARALLEL PIN 12X20 |
| PARTS NO. | DESCRIPTION |
| 129930-07910 | LIFTER, ENGINE |
| 129910-07910 | LIFTER, ENGINE |
| 129903-11700 | HEAD ASSY,CYLINDER |
| 129900-11100 | VALVE, SUCTION |
| 129900-11110 | VALVE, EXHAUST |
| 129900-11120 | SPRING, VALVE |
| 129795-11180 | RETAINER, SPRING |
| 121400-11340 | SEAL, VALVE STEM |
| 124460-11340 | SEAL, VALVE STEM |
| 129150-11370 | CAP, VALVE |
| 129901-11450 | PROTECTER, NOZZLE |
| 119600-11460 | GASKET, NOZZLE |
| 23871-005000 | PLUG PT 1/16 |
| 23876-030000 | PLUG PT3/8,SCREW |
| 27241-400000 | PLUG 40 |
| 27310-080001 | COTTER 8 |
| 129150-11810 | GUIDE, VALVE |
| 129900-11200 | SUPPORT ASY,ROCK.ARM |
| 129900-11240 | SHAFT ASSY,ROCK. ARM |
| 129900-11280 | SPRING |
| 129900-11510 | SUPPORT |
| 129900-11520 | SUPPORT |
| 129900-11650 | ARM KIT, SUC. ROCKER |
| 129150-11230 | SCREW, VALVE |
| 129150-11750 | NUT M8XP1.0 |
| 129900-11660 | ARM KIT, EXH. ROCKER |
| 129150-11230 | SCREW, VALVE |
| 129150-11750 | NUT M8XP1.0 |
| 22242-000180 | CIRCLIP 18 |
| 26577-040162 | SCREW M 4X 16 |
| 129900-11530 | STUD BOLT |
| 26306-100002 | NUT |
| 124160-01751 | COVER,FILLER |
| 124160-11360 | KNOB |
| 129900-11370 | BONNET ASSY |
| 129900-11310 | GASKET, BONNET |
| 129900-11600 | PLATE |
| 22857-500100 | SCREW 5X10,TAPPING |
| 27225-080080 | PLUG 8X 8 |
| 24311-000120 | O-RING 1A P 12.0 |
| 24311-000320 | O-RING 1A P-32.0 |
| 119717-77800 | PLUG, GLOW |
| 129901-77820 | CONNECTOR, GLOW PLUG |
| 26106-080162 | BOLT M 8X 16 PLATED |
| 26106-100652 | BOLT M10X 65 PLATED |
| 119326-77820 | COVER, GLOW PLUG |
| PARTS NO. | DESCRIPTION |
| 129900-12050 | GASKET, SUC.MANIFOLD |
| 129900-12100 | MANIFOLD,INT |
| 26106-080452 | BOLT M 8X 45 PLATED |
| 129900-13120 | MANIFOLD, EXHAUST |
| 129900-13150 | GASKET |
| 119802-13610 | BOLT M 8X 45 PLATED |
| 119131-18320 | BOLT M 8X 22 |
| 119802-13720 | STUD, M8X45 |
| 26306-080002 | NUT |
| 121850-77021 | GASKET, (NON-ASB.) |
| 121959-12140 | JOINT |
| 26106-080352 | BOLT M 8X 35 PLATED |
| 129930-13201 | GASKET, SILENCER |
| PARTS NO. | DESCRIPTION |
| 129150-14200 | TAPPET |
| 129900-14400 | ROD, PUSH |
| 129900-14590 | CAMSHAFT ASSY |
| 129150-02450 | METAL,THRUST(CAM |
| 129900-14110 | GEAR, CAMSHAFT |
| 22512-070140 | KEY 7X 14 |
| 26106-080142 | BOLT 8X 14 PLATED |
| 129900-25060 | SHAFT, IDLER |
| 129900-25110 | GEAR ASSY, IDLE |
| 129150-25920 | BUSH, IDLE GEAR |
| 26106-080552 | BOLT M 8X 55 PLATED |
| 129901-25900 | GEAR, FI-P |
| 129900-26020 | GEAR ASSY, HYDR.PUMP |
| 22217-140000 | SPRING WASHER 14 |
| 26776-140002 | LOCK NUT M14 PLATED |
| PARTS NO. | DESCRIPTION |
| 129902-21050 | CRANKSHAFT COMP |
| 129900-21220 | GEAR, CRANKSHAFT |
| 121850-21290 | PARALLEL PIN |
| 121850-21920 | PARALLEL PIN 10X22 |
| 22512-070140 | KEY 7X 14 |
| 129907-21650 | V-PULLEY,CRANKSHAFT |
| 129960-21640 | WASHER |
| 129916-21610 | BOLT, V-PULLEY |
| 129903-22120 | PISTON ASSY |
| 129903-22050 | RING SET |
| 120130-22301 | PIN, PISTON |
| 22252-000300 | CIRCLIP 30 |
| 129900-23001 | ROD ASSY, CONNECTING |
| 129900-23200 | BOLT, ROD |
| 129900-23601 | METAL ASSY, CRANKPIN |
| 129900-23911 | BUSH, PISTON PIN |
| 129903-22940 | PISTON W/RING OS=.25 |
| 129903-22950 | RING SET O.S=0.25 |
| 129900-23611 | BEARING,PIN U.S=0.25 |
| 121850-21130 | BOLT, FLYWHEEL |
| 129906-21520 | FLYWHEEL CMP |
| 129900-21600 | GEAR, RING |
| 129930-21690 | BEARING |
| 24341-000530 | O-RING 1A S-53.0 |
| 8. LUB.OIL SYSTEM | (A)=4TNE98-BQFLC |
| LEV. PARTS NO. | DESCRIPTION |
| 129930-34800 | DIPSTICK |
| 119260-34810 | GUIDE, DIPSTICK |
| 129930-34810 | GUIDE, DIPSTICK |
| 24311-240100 | O-RING 1A P-10A |
| 26106-080162 | BOLT M 8X 16 PLATED |
| 129150-35160 | FILTER 80X80L |
| 119000-35140 | STUD, LUB.OIL FILTER |
| 129900-32030 | O-RING P20 |
| 129930-35000 | PIPE ASSY, LUB. OIL |
| 26106-080122 | BOLT M 8X 12 PLATED |
| 114250-39450 | SWITCH,(0.5KG)L.O. |
| 129930-39050 | PIPE |
| 105010-39140 | BOLT, PIPE JOINT |
| 22190-080002 | SEAL WASHER 8S |
| PARTS NO. | DESCRIPTION |
| 26106-080552 | BOLT M 8X 55 PLATED |
| 129900-42461 | PULLEY |
| 25132-004300 | V-BELT |
| 129916-44740 | FAN |
| 26014-080352 | BOLT M 8X 35 |
| 121850-49550 | GASKET, THERMOSTAT |
| 129900-49551 | COVER, THERMOSTAT |
| 129900-49560 | GASKET, (NON-ASB.) |
| 121850-49810 | THERMOSTAT |
| 26106-080252 | BOLT M 8X 25 PLATED |
| 171056-49120 | PLUG, DRAIN |
| 129900-42061 | GASKET, C.W.PUMP |
| 129917-42010 | PUMP ASSY, WATER |
| 129916-49740 | PLUG, DRAIN R03 |
| 129900-42140 | O-RING P36 |
| 129917-42160 | COVER |
| 129917-42170 | GASKET |
| 129917-42300 | OUTLET FLAMGE |
| 129917-42310 | GASKET, MECHANICAL |
| 26106-060202 | BOLT M 6X 20 PLATED |
| 26577-060142 | SCREW M 6X 14 |
| 23875-010000 | PLUG PT1/8 |
| 129107-44901 | SENSOR,HOT WATER |
| 124465-44950 | GASKET 16 |
| 119130-44760 | SPACER, FAN |
| 124250-49351 | THERMOMETER |
| 129150-49360 | GASKET 10 |
| PARTS NO. | DESCRIPTION |
| 129904-01950 | RETAINER |
| 129901-01960 | STAY, BRACKET |
| 26106-100142 | BOLT M10X 14 PLATED |
| 26106-100162 | BOLT M10X 16 PLATED |
| 26106-100202 | BOLT M10X 20 PLATED |
| 129919-51500 | PUMP ASSY, FUEL OIL |
| X1466000800 | O RING |
| X1466000800 | O RING |
| X1463104020 | COVER |
| X1466205000 | BOLT |
| X1463105100 | COVER |
| X1466205000 | BOLT |
| X1466501220 | VALVE |
| X1466001700 | O RING |
| X1466584820 | WIRE |
| X1466214901 | NUT |
| X1465981000 | CAP |
| X0299985720 | CAP |
| X0294704030 | WOODRUFF KEY |
| X0131214140 | NUT |
| X0293214050 | SPRING WASHER |
| X1466214901 | NUT |
| X1466005000 | O RING |
| X1466629920 | WIRE |
| 129930-67010 | BRACKET, AXEL WIRE |
| 26450-060252 | BOLT M 6X 25 |
| PARTS NO. | DESCRIPTION |
| 129931-53000 | VALVE ASSY,INJECTION |
| 119717-53010 | NOZZLE ASSY |
| 129901-53020 | RETAINER |
| 129901-53800 | SHIM SET |
| 119305-59120 | RETAINER |
| 129150-59131 | BOLT M4X14,HEX.SCKT. |
| 129550-59120 | RETAINER |
| 129150-59131 | BOLT M4X14,HEX.SCKT. |
| 129901-59810 | PIPE NO.1, F.INJECT. |
| 129901-59820 | PIPE NO.2, F.INJECT. |
| 129901-59830 | PIPE NO.3, F.INJECT. |
| 129901-59840 | PIPE NO.4, F.INJECT. |
| 105225-59500 | PIPE ASSY,F.O.RETURN |
| 124066-59100 | CLAMP 8 |
| 129901-59510 | PIPE, FUEL RETURN |
| 129901-59560 | GASKET, RETURN |
| 119620-59700 | NUT |
| PARTS NO. | (C)= DESCRIPTION |
| 129917-55801 | FILTER ASSY, FUEL OI |
| 129917-55810 | BODY ASSY, FILTER |
| 129917-55821 | SENSOR ASSY, LEVEL |
| 129917-55830 | PLUG, DRAIN |
| 129917-55840 | O-RING |
| 129917-55850 | ELEMENT ASSY, FILTER |
| 26106-080252 | BOLT M 8X 25 PLATED |
| 129901-59500 | PIPE, FUEL |
| 23000-013000 | CLAMP 13 |
| 105430-67110 | CLAMP |
| 129052-55630 | STRAINER,FUEL OIL(IN |
| 198072-04320 | CLAMP |
| PARTS NO. | (C)= DESCRIPTION |
| 129900-77010 | STARTER(2.3KW |
| 129900-77400 | ARMATURE ASSY |
| X2114155110 | BALL BEARING |
| X2114255110 | BALL BEARING |
| 129900-77440 | COIL ASSY, FIELD |
| 171008-77450 | SCREW, POLE CORE SET |
| 129900-77450 | BRUSH (+) |
| 129900-77480 | HOLDER ASSY, BRASH |
| 129900-77450 | BRUSH (+) |
| X2130631300 | BRUSH SPRING |
| 129900-77460 | COVER, REAR |
| 129900-77591 | SWITCH ASSY,MAGNETIC |
| 129900-77620 | SHIFT LEVER SET |
| 129900-77650 | COVER ASSY, DUST |
| 129900-77640 | BOLT, THROUGHT |
| 129900-77700 | GEAR CASE ASY |
| 129900-77510 | PINION ASSY |
| 129900-77540 | SHAFT, PINION |
| 129900-77550 | STOPPER SET |
| 129900-77520 | CLUTCH ASSY |
| 171008-77730 | BALL BEARING (3) |
| 171008-77740 | BALL BEARING (4) |
| 129900-77610 | RETAINER, BEARING |
| 129900-77710 | HOUSING, GEARS |
| 171008-77750 | COVER, M TERMINAL |
| 26116-120302 | BOLT M12X 30 PLATED |
| PARTS NO. | (C)= DESCRIPTION |
| 129930-77212 | GENERATOR |
| 129612-77700 | ROTOR ASSY |
| 129612-77710 | BALL BEARING |
| 129612-77730 | FRONT BRACKET ASSY |
| 129930-77740 | PULLEY |
| 129612-77750 | SCREW KIT |
| 129930-77930 | BRACKET, REAR |
| 129136-77251 | BOLT M 8X110 |
| 129612-77260 | NUT ,GENERATOR |
| 129150-77340 | SPACER |
| 129900-77330 | AJUSTER, BELT |
| 119810-77340 | BOLT |
| 26014-080252 | BOLT M 8X 25 |
| 129930-77970 | QGS CONTROLLER (CSD |
| PARTS NO. | (C)= DESCRIPTION |
| 729903-92760 | GASKET SET(NON-ASB.) |
| 129903-01350 | GASKET, HEAD |
| 124460-11340 | SEAL, VALVE STEM |
| 129901-11450 | PROTECTER, NOZZLE |
| 119600-11460 | GASKET, NOZZLE |
| 129900-11310 | GASKET, BONNET |
| 129900-12050 | GASKET, SUC.MANIFOLD |
| 129900-13150 | GASKET |
| 121400-11340 | SEAL, VALVE STEM |
| 129900-32030 | O-RING P20 |
| 129900-32040 | O-RING P14 |
| 129900-42061 | GASKET, C.W.PUMP |
| 129900-49560 | GASKET, (NON-ASB.) |
| 121850-49550 | GASKET, THERMOSTAT |
| 129901-59560 | GASKET, RETURN |
| 22190-220002 | SEAL WASHER 22S |
| 124465-44950 | GASKET 16 |
| 24311-240100 | O-RING 1A P-10A |
| 24311-000120 | O-RING 1A P 12.0 |
| 24311-000320 | O-RING 1A P-32.0 |
| 24341-000500 | O-RING 1A S-50.0 |
| 22190-080002 | SEAL WASHER 8S |
| 24321-000850 | O-RING 1A G-85.0 |
| 129150-49360 | GASKET 10 |
| 129900-42140 | O-RING P36 |
| 121850-77021 | GASKET, AIR HEATER |
| 24341-000530 | O-RING 1A S-53.0 |
| 129930-13201 | GASKET, SILENCER |
| 129400-92450 | FLEX HONE |
| 977770-1207F | GASKET.LIQUID |
