Description

TC03311020032 cover foton tractor parts

FT300.53.001 Traction Equipment Assembly 1
1 FT300.53.106 Traction Pin 1
2 FT300.56.029 Lock Pin Assembly 2
3 FT300.53.108a Traction Frame 1
4 FT65.53.103 Elastic Lock Pin 2
5 FT300.53.101a Connecting Pin 2
6 FT300.53.102 Traction Pin 1
7 FT300.53.103 Supporting Sleeve 1

TB500A.55 Lift Mechanism Assembly 1
FT300.55B.023 Control Lever Positioning Assembly 1
1 FT65.57.014 Adjusting Lever Head Assembly 2
2 FT300.55B.133 Positioning Bending Plate 2
3 GBT 818-M5X16-4.8-A2L Screw 4
4 GBT 93-5-A0P Standard Spring Washer 4
5 FT300.55B.131 Washer 4
6 FT300.55B.132 Positioning Nut 2
7 GBT 91-1.6X12-A0P Cotter Pin 2
8 FT300.55B.135 Force Adjusting Mark Plate 1
9 FT300.55B.134 Position Adjusting Mark Plate 1

TB500A.55 Lift Installation Assembly 1
1 FT300.55B.016c Breather Assembly 1
1.1 FT700.55D.136 Breather Cover 1
1.2 GBT 893.1-26 Circlip For Hole 1
1.3 FT650.40.167 Seat Plate 2
1.4 FT700.55D.109 Breather Filter Element 1
1.5 FT300.55B.164 Breather Bracket 1
1.6 FT300.55B.027a Breather Connecting Pipe Weldment 1
2 GBT 5783-M10X20-8.8-A3L Hexagon Head Bolt 2
3 GBT 97.1-10-A0P Flat Washer 4
4 GBT 93-10-A0P Standard Spring Washer 2
5 GBT 6170-M10-8-A3L Hexagon Nut, Style 1 2
6 GBT 5783-M8X30-10.9-A2L Hexagon Bolt 2
7 Q67512 Type A Worm Transmission Hose Clamp 2
8 FT300.55B.169 Breather Connecting Pipe 2 1
9 TA700.55A.7-01a Oil Pipe Plug 1
10 GBT 5783-M8X25-8.8-A2L Hexagon Head Bolt 2
11 GBT 93-8-A0P Standard Spring Washer 2
12 FT300.55B.026a Oil Filling Pipe Weldment 1
13 GBT 3452.1-32.5X1.80G O-Ring Sealant Used For Hydraulic Or Pneumatic Parts 1
14 FT300.55B.022a Adjusting Nut 1
15 SPL-CO-M12-10-F3 Hexagon Nut 2
16 TB404.312B-01 Washer 7
17 GBT 5783-M12X100-10.9-A3L Hexagon Head Bolt 2
18 FT300.55B.136 Bolt M12x240 2
19 FT300.55B.121a Oil Delivery Pipe Nut 1
20 JBT 982-22 Combined Sealing Washer 3
21 FT300.55B.024 Oil Drainage Pipe Weldment Assembly 1
22 FT300.58.101 Hollow Bolt 1
23 GBT 5783-M12X40-10.9-A3L Hexagon Head Bolt 3
24 FT500A.55.010 Lift And Control Mechanism Assembly 1
25 GBT 16674.1-M12X35-10.9-A2L Hexagon Head Bolt 4

26 GBT 3452.1–103X2.65G O-Ring Seal 1
27 TB300.55-02 Washer 2
28 GBT 68-M4X10-4.8-A2L Slotted Countersunk Head Screw 2
29 TB504.552-04 Handle Head 2
30 JBT 982-33 Combined Sealing Washer 1
31 TB300.55-01 Double-Headed Stud M12x250 2

TB500A.55 Lift Mechanism Assembly 1
FT500A.55.010 Lift And Control Mechanism Assembly 1
1 GBT 5781-M10X20 Bolt 2
2 GBT 93-10 Washer 5
3 FT500B.55.127 Lift Arm Press Plate 2
4 FT500A.55B.016 Lift Arm Assembly 2
5 FT500B.55.115A Lift Shaft Bush B 2
6 GBT 1235-60X5.7 O-Ring 2
7 FT500B.55.122A Shaft Bush 1
8 FT500A.55.110 Lift Shaft 1
9 GBT 882-B5X65 Shaft Pin 1
10 FT500B.55.113E Inner Lift Arm 1
11 FT500B.55.114D Piston Push Rod 1
12 GBT 97.1-5 Washer 1
13 GBT 91-2X12 Pin 1
14 KM550.55.105-1 Shaft Sleeve 1
15 GBT 5783-M10X35 Bolt 1
16 KM550.55.109 Cam 1
17 FT500B.55.104B Shaft Bush 1
18 FT500B.55.197 Plug 1
19 GBT 3452.1-22.4X1.8 O-Ring 1
20 FT300.55B.121a Oil Delivery Pipe Nut 1
21 GBT 3452.1-12.5X2.65 O-Ring 1
22 GBT 5783-M10X25 Bolt 2
23 FT300.55B.120a Hydraulic Output Pipe Joint 1
24 GBT 1235-16X2.4 O-Ring 2
25 FT500B.55.105 Oil Outlet Pipe 1
26 GBT 1235-24X2.4 O-Ring 1
27 GBT 5781-M6X16 Bolt 2
28 GBT 93-6 Washer 2
29 YT300A.55.122 Cut-Off Valve Limitation Plate 1
30 BY350.55.163 Adjusting Valve Screw Lever Handle 1
31 FT500B.55.126 Cut-Off Valve Adjusting Lever 1
32 GBT 1235-13X1.9 O-Ring 2

TB500A.55 Lift Mechanism Assembly 1
FT500A.55.010 Lift And Control Mechanism Assembly 1
1 GBT 5782-M8X45 Bolt 4
2 GBT 93-8 Washer 8
3 GBT 5782-M8X50 Bolt 4
4 JBT 1000-M12X1.5 Screw Plug 2
5 JBT 982-12 Compound Seal Washer 2
6 GBT 3452.1-25.7X2.65 O-Ring 1
7 GBT 1235-24X2.4 O-Ring 1
8 YT300A.55.124 Single-Way Valve Sleeve 1
9 T30.57.164 Single-Way Valve Body Gasket 1
10 T30.57.144B Single-Way Valve Spring 1
11 GBT 3452.1-19X2.65 O-Ring 1
12 T30.57.142B Single-Way Valve Body 1
13 T30.57.143B Single-Way Valve Seat 1
14 KM550.55.120E Distributor Housing 1
15 JBT 982-10 Compound Seal Washer 2
16 JBT 1000-M10X1 Screw Plug 2
17 FT500B.55.246 Cutoff Valve 1
18 GBT 3452.1-11.8X2.65 O-Ring 1
19 FT500B.55.107 Distributor Bracket 1
20 TS300B.55.211 Safety Valve Spring Seat 1
21 TS300B.55.210 Aluminum Gasket 1
22 12.55.218 Safety Valve Spring 1
23 TS300B.55.209 Safety Valve Body 1
24 GBT 308-φ6 Ⅱ Steel Ball 1
25 GBT 6173-M16X1.5 Nut 1
26 TS300B.55.251 Pressure Adjusting Stud 1
27 GBT 3452.1-13.2X2.65 O-Ring 1
28 KM550.55.023 Piston Assembly 1
29 520.55.143 Circlip 1
30 GBT 3452.1-90X5.3 O-Ring 1
31 FT500B.55.106 Cylinder Body 1
32 GBT 3452.1-17X2.65 O-Ring 4
