Description

13022348 WEICHAI PISTON

1 VG1500150023 1 油底壳总成 Oil sump assembly
2 VG14150004 1 密封垫 Seal
3 VG2600150108 1 磁性螺塞总成 Magnetic screw plug
4 VG2600150106 1 密封垫圈 Sealing washer
5 90003802442 12 Q150B0840 六角头螺栓 Hex head bolt
6 90003932023 12 Q41808 波形弹簧垫圈 Wave spring washer
7 90003930261 12 平垫圈 Flat washer
8 VG14150046 12 油底壳托块 Retainer

Cylinder block ass AZ1095010033
Cylinder block AZ1095010031
Crankcase 61500010366C
Bush VG2600010990
Bush VG1560010029
Bush VG1096010010A
Core plug 190003989480
Core plug 190003989204
Core plug 190003989289
Core plug 190003982121
Core plug 190003989215
Core plug 190003989288
Core plug 190003989210
Bolt VG14010217
Pipe VG2600070097
Dowel pin 90003901604A
Dowel pin Q5211220
Bolt VG14010114
Stud VG1500010185
Bolt 190003802493
Gasket VG407010046
Bolt VG1460070011
Gasket VG2600010735

Dowel pin 190003900085
Spring dowel pin 190003909626
Bolt Q617B18
Liner VG1540010006
Main bearing VG1540010021
Main bearing VG1540010022
Thrust bearing VG1500010125
Spraying nozzle assembly VG1560010090
Spraying nozzle assembly VG2600010659
Spring dowel pin 190003909603
Bolt 190003962621
Gasket 190003962020
Front gasket VG1047010038
Back gasket VG1047010050
Gear case 61557010008
Bolt 90003802523
Bolt 90003802561
Bolt 90003802571
Spring washer 190003931122
Gasket VG288730061
Dowel pin 190003901507
Gasket VG61000010134
Front gasket bracket VG2600010928
