No.

Part

Drawing No.

Qty.

No.

Part

Drawing No.

Qty.

1

Steering knuckle unit (RH)

5142019/12

1

6

Limit Bolt M10×1.25×30

5126628/1.40.211

2

1.1

Bushing, steering knuckle

5104199/1.04.228

2

7

Ball pivot pair, kingpin

5119699/1.40.240

4

1.2

Steering knuckle (RH)

5142001/12

1

8

Seal ring

5121471/1.40.232

4

2

Bolt M12×1.25×30

14274534/10352/04

12

9

Steering knuckle unit (LH)

5142018/12

1

3

Oil cup M10×1

GB 1152-79

4

9.1

Steering knuckle (LH)

5142002/12

1

4

Kingpin, steering knuckle

5137239/12

4

10

Oil seal 165×190×17

8A5137109/12

2

5

Adjusting shim 0.10mm

5137456/12

As needed

11

Nut

5142020/12

2

Adjusting shim 0.15mm

5137457/12

As needed

12

Bearing, wheel hub (FR)

5136951/12

4

Adjusting shim 0.20mm

5137458/12

As needed

95×35×20

Adjusting shim 0.25mm

5137459/12

As needed

13

Wheel hub (FR) with dowel pin

8A5142014/13

2

Adjusting shim 0.30mm

5137460/12

As needed

13.1

Hub, traction wheel (FR)

8A5142013/13

2

13.2

Dowel pin 12×20

4985063/1.21.067

2

No.

Part

Drawing No.

Qty.

No.

Part

Drawing No.

Qty.

1

2

3

4

Tie rod assembly

Prevailing torque type nut M18×1.5

Ball joint assembly Locking thin nut M24×1.5 Tie rod unit

5142233/14

12576014/10125

5117314/1.40.516B

10726914/10114

5142234/14

1

2

1

1

1

No.

Part

Drawing No.

Qty.

No.

Part

Drawing No.

Qty.

1

Locking bolt

14274634/10357/04

10

2.5

Locking bolt

14275334/10357/04

4

M12×1.25×35

M12×1.25×70

2

Support unit, bevel drive

144526/15

1

2.6

Bearing cap, support, bevel

4996748/1.41.005

1

2.1

Dowel pin 5×15

4966244/1.41.016

4

drive

2.2

Axle seat, support, bevel

5136120/15

1

3

Adjusting nut M100×2

4996750/1.41.008

2

drive

4

Bolt M10×1.25×20

GB 5786-86

2

2.3

Anti-friction ring (RR)

5136119/15

1

5

Stop plate, adjusting nut

4996751/1.41.015

2

2.4

Support, bevel drive

5144525/15

1

6

Locking plate, adjusting nut

562659/1.41.032

2

No.

Part

Drawing No.

Qty.

No.

Part

Drawing No.

Qty.

1

Locking nut, bevel

5143242/16

1

10

Bevel gear pair

5142249/16

1

1

1

8

1

1

1

2

2

2

2

2

2

2

1

1

1

2

pinion

10.1

Bevel pinion pair

5142248/16

2

Collar, oil seal

4997451/1.41.143

1

10.2

Bevel gear wheel

5140753/16

3

Oil seal, shaft, bevel pinion 45×75×10-12

5135294/16

1

11

Locking nut M12×1.25×25

14274434/10357/4

4

O-ring 31.5×1.8

GB 3452.1-82

1

12

Differential assembly

5117219/1.41.402

5

Steel ball 6.3500G10B

GB 308-84

1

12.1

Dowel, shaft,

4987976/1.32.428

6

Oil seal ring, shaft, bevel

5142026/16

1

planetary gear

pinion

12.2

Carrier, differential

4996747/1.41.402

7

Bearing (RR), shaft, bevel pinion

5133776/16

1

12.3

Thrust washer, planetary gear

4987975/1.32.425

8

9

Bearing (FR), shaft, bevel pinion

Adjusting washer, bevel pinion

5143109/16

5142027/16 thickness 2.5

5142028/16 thickness 2.6

1

As needed

12.4

12.5

Pinion, differential

Thrust washer, side gear

5103870/1.32.415B

5148936/1.32.424 thickness 1.6

5148937.1.32.424 thickness 1.8

5142029/16 thickness 2.7

5148937.1.32.424 thickness 1.7

5142030/16 thickness 2.8

5148939.1.32.424 thickness 1.5

5142031/16 thickness 2.9

5148940.1.32.424 thickness 1.4

5142032/16 thickness 3.0

12.6

Side gear (RH)

5110716/1.41.502

5142033/16 thickness 3.1

12.7

Shaft, pinion,

5148935/1.32.416

5142034/16 thickness 3.2

differential

5142035/16 thickness 3.3

12.8

Side gear (LH)

5103868/1.32.413

5142036/16 thickness 3.4

13

Conical bearing

GB 297–84

5142037/16 thickness 3.5

2007112E

5142038/16 thickness 3.6

5142039/16 thickness 3.7

No.

Part

Drawing No.

Qty.

No.

Part

Drawing No.

Qty.

1

Retainer ring 35

GB/T894.1-1986

2

9

Sun gear

5137107/20

2

2

Retainer ring 62

GB/T893.1-1986

4

10

Baffle ring, ring gear

4997571/1.41.549

2

3

Bearing 107 (35×62×14)

GB/T276-1994

2

11

Support, ring gear

5142047/20

2

4

Oil seal, half axle

5136002/1.41.538

2

12

Ring gear

5108747/1.41.543

2

40×62×10

13

Planet carrier unit

5137724/20

2

5

Collar, oil seal, half axle

4996762/1.41.537

2

13.1

Retainer, bearing, planetary

4997510/1.41.552

12

6

Cardan shaft assembly (LH)

5142043/20

1

gear 20×45×0.8

Cardan shaft assembly (RH)

5142040/20

1

13.2

Planetary gear

5108747/1.41.545

6

6.1

Long fork shaft (LH)

8A5142043-1/20

1

13.3

Needle bearing

5101693/1.41.546

6

Long fork shaft (RH)

8A5142040-1/20

1

25.6×35.6×29.8

6.2

Retainer ring

885142040-6/20

16

13.4

Planet carrier

5137689/20

2

6.3

Needle bearing assembly

885142040-5/20

16

13.5

Shaft, planetary gear

4997509/1.41.547

6

6.4

6.5

6.6

7

8

Spider Double fork

Short fork shaft

Oil seal, drive fork shaft 42×62×17

Circlip for shaft

885142040-4/20

885142040-2/20

88514204-3/20

885133799/1.41.539

5140018/20

4

2

2

2

4

14

15

16

Rectangular cross-section seal ring 22×28×1.5

Hexagon head plug M22×1.5

Locking bolt M10×1.25×30

10263460/14607

10305114/14530

14233634/10357/04

2

2

24
