2409001210306 QC490 QC495 QUANCHAI GEAR CASE

TB400.11 Air Cleaner Assembly 1
1 Q67683 Type-B Worm Drive Hose Clamp 2
2 TB400.11-01 Air intake hose of air filter 1
3 TB400.11.1 Air filter assembly 1
4 GBT 5783-M8X25-A2L Hex bolt 2
5 GBT 93-8-A0P Standard spring washer 6
6 TB400.11.2 Air filter installation bracket weldment 1
7 GBT 97.1-8-A0P Flat washer 4
8 GBT 6170-M8-A2L Type 1 hex nut 2
9 GBT 5783-M8X16-A2L Hex bolt 2

TB500.13Y Cooling system assembly 1
1 Q67650 Type-B worm drive hose clamp 4
2 TB500.13-01 Water inlet hose 1
3 TB500.13Z.1 Radiator assembly 1
4 TB500.13E.2 Pull rod unit 2
5 FT450.13.102 Water outlet hose 1
6 GBT 6170-M8-8-A2L Type 1 hex nut 2
7 GBT 93-8-A0P Standard spring gasket 8
8 GBT 96.1-8-A0P Big washer 4
9 GBT 5783-M8X20-8.8-A2L Hex bolt 6
10 TB500.13Y.5 Air filter installation trestle 1
11 GBT 97.1-8-A0P Flat washer 4
12 TA700.131-01 Rubber pad block 2
13 GBT 5783-M10X20-8.8-A3L Hex bolt 2
14 GBT 93-10-A0P Standard spring gasket 2
15 GBT 97.1-10-A0P Flat washer 2
16 TB500.13Y.2 Water tank pad plate weldment 1
17 FT650.13.116 Gasket 2
18 GBT 6178-M10-8-A3L Slotted nut 2
19 GBT 91-2.5X28-A0P Cotter pin 2
20 TA700.131-02 Sleeve 2
21 TD800.131-11 Rubber pad 2

TB400.201F Handle throttle assembly 1
1 TA700.201-01 Handle throttle assembly 1
2 GBT 93-6-A0P Washer 3
3 GBT 5781-M6X16-A2L Bolt 3
4 FT700.20.324 Handle throttle cover 1
5 GBT 5780-M10X45-A3L Bolt 1
6 GBT 96-10-A0P Washer 1
7 GBT 68-M8X30-A2L Screw 3
8 GBT 6170-M8-A2L Nut 3
9 GBT 97.1-8-A0P Washer 1
10 FT650.20.133 Locking screw 1
11 GBT 818-M8X20-A2L Screw 2
12 FT300.20.105 Handle throttle wire trestle 1
13 GBT 93-8-A0P Washer 2

TB400.202F Foot throttle assy 1
1 GBT 5783-M6X20-8.8-A2L Hex head bolt 1
2 TB300.202-01 Foot pedal 1
3 TB400.202E.1 Foot throttle control sub-assembly 1
3.1 FT650.20.107 Rubber plug 1
3.2 TB300.202.1 Foot pedal rocker arm weldment 1
3.3 FT650.20.108 Throttle support 1
3.4 GBT 6172.1-M8-04-A2L Hexagon thin nut 1
3.5 GBT 5781-M8X45-4.8-A2L Hex head bolt 1
3.6 FT650.20.104 Torsion spring 1
3.7 FT650.20.114 Hand throttle rocker arm 1
3.8 FT300.20.011 Foot throttle rocker arm weldment 1
3.9 GBT 879.1-5X20 Elastic cylindrical pin 1
3.10 FT650.20.133 Tightening screw 1
3.11 GBT 97.1-8-A0P Flat washer 1
3.12 GBT 6170-M8-8-A2L Hexagon nut , Style 1 1
4 GBT 6172.1-M8-04-A2L Hexagon thin nut 2
5 GBT 818-M8X20-4.8-A2L Cross recessed pan head screw 4
6 GBT 93-8-A0P Standard spring washer 4
7 FT300.20.016 Foot throttle cable bracket weldment 1
8 GBT 5783-M5X12-8.8-A2L Hex head bolt 3
9 GBT 97.1-5-A0P Flat washer 3
10 FT65.45.393 Throttle pedal sealing gland 1
11 FT65.45.394 Accelerator pedal gland plate 1
12 GBT 6170-M8-8-A2L Hexagon nut, Style 1 2
13 GBT 93-5-A0P Standard spring washer 3

TB400.203B Throttle wire assembly 1
1 FT650.20.014 Foot throttle pull wire assembly 1
2 GBT 91-2X12-A0P Pin 1
3 GBT 882-B5X20-A0P Pin shaft 1
4 FT400.20.018 Flameout pull wire assembly 1

TB550.22A Exhaust system assembly 1
1 TB550.22A.1 Muffler assembly 1
2 FT300.22.030 Seal gasket unit 2
3 TB550.22A-03 Exhaust bending pipe 1
4 TB550.22A-02 Lower shield screen of exhaust pipe 1
5 GBT97.1-8-A0P Flat washer 4
6 GBT93-8-A0P Standard spring washer 4
7 GBT5783-M8X20-8.8-A2L Hex bolt 4
8 SPL6175PT-M10X1.5-8F3 Hex self locking spiralock nut, style 2 4
9 GBT5783-M10X40-8.8-A3L Hex bolt 4
10 TB550.22A-01 Upper shield screen of exhaust pipe 1
11 GBT95-10-A0P Flat washer 4
12 GBT93-10-A0P Standard spring washer 4
13 GBT5783-M10X30-8.8-A3L Hex bolt 4
