LOVOL FT404–AK16 Tractor Parts Catalogue 19

Meppon Parts Posted on by



FT400.50B.001 50–ᆳၒᇑ@ॐጺׯ



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

1

TA650.502.3

OIL TANK COVER ASSEMBLY

1

2011–11_

10

FT300.50.110

FRONT RUBBER WASHER

2

2011–11_

11

FT300.50B.020

OIL TANK BRACKET ASSEMBLY

1

2011–11_

11.1

GBT6170–M10

NUT M10

1

2011–11_

11.1

GBT6170–M10–Zn.D

NUT

1

2011–11_



11.2



FT300.50.125



OIL TANK SUPPORT FRAME



2



2011–11_

11.3

FT300.50B.124

OIL TANK GASKET PLATE

1

2011–11_

11.3

FT300.50B.124

OIL TANK GASKET PLATE

1

2011–11_

11.4

GBT93–8

WASHER 8

6

2011–11_

11.5

GBT6170–M8–Zn.D

NUT

6

2011–11_



11.6



FT300.50.126



CONNECTING PLATE



2



2011–11_

11.7

FT300.50.123

U–BRACKET

1

2011–11_

11.8

GBT5783–M10×20

BOLT

4

2011–11_

11.9

GBT93–10

WASHER 10

4

2011–11_

12

GBT6170–M10–A3L

NUT

8

2011–11_



13



FT404.50.114



MAIN OIL TANK BELT RUBBER WASHER



2



2011–11_

14

FT300.50.014

OIL TANK BAND ASSEMBLY

2

2011–11_

15

GBT97.1–10–A0P

WASHER

2

2011–11_

16

FT300.50B.016

U–PLATE WELDMENT

1

2011–11_

17

GBT93–10–A0P

WASHER

1

2011–11_



18



GBT5783–M10x20–A3L



BOLT



1



2011–11_

19

FT300.50.112

RUBBER PAD BLOCK

2

2011–11_

2

FT300.50.015

FILTER MESH ASSEMBLY

1

2011–11_

3

FT400.50.011a

OIL TANK WELDMENT ASSEMBLY

1

2011–11_

4

JBT982–16

COMBINED SEAL GASKET

1

2011–11_

212








213





FT400.50B.001



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

5

6

6

7

7



8

9

FT65.50.226 FT65.50.033 FT65.50.033 JBT982–14 JBT982–14



FT65.50.106 FT300.50.111

OIL DISCHARGING SCREW PLUG SEDIMENT CUP ASSEMBLY SEDIMENT CUP ASSEMBLY COMBINED SEAL GASKET COMBINED SEAL GASKET



HOLLOW BOLT

REAR RUBBER CUSHION

1

1

1

2

2



1

2

2011–11_

2011–11_

2011–11_

2011–11_

2011–11_



2011–11_

2011–11_

214








215





FT300.55B.001–1 55.1–༵ืഗጺׯ–1 LIFTER ASSEMBLY–1



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

0

0

1

2

3



4

6

7

8

9

FT300.55B.010
TB–B02223
FT65.57.014
GBT818–5×16
GBT93–5



GBT97.1–5
FT300.55B.132
FT300.55B.133
FT300.55B.134
FT300.55B.135

LIFTER ASSEMBLY
TOOL KIT

ADJUSTING HANDLE HEAD ASSEMBLY
SCREW

WASHER



WASHER
LOCATING NUT

LOCATING BENDING PLATE

POSITION ADJUSTING POSITION MARK
FORCE ADJUSTING POSITION MARK



216












217





FT300.55B.001–2 55.2–༵ืഗጺׯ–2 LIFTER ASSEMBLY–2



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

1

FT500B.55.101A

LIFTER HOUSING

1

2011–11_

11

FT500B.55.118

LOCK SHIM

1

2011–11_

14

TS300B.55.110

SPRING HOOK

1

2011–11_

16

FT500B.55.197

PLUG

2

2011–11_

17

FT500B.55.102

OIL INLET CONNECTING PLATE PAPER GASKET

1

2011–11_



19



FT500B.55.103



OIL INLET PIPE



1



2011–11_

2

YT300A.55.116

LOW SPEED CONTROL LEVER

1

2011–11_

20

FT500B.55.108A

OIL INLET CONNECTING PLATE

1

2011–11_

23

FT500B.55.115A

LIFTING SHAFT SLEEVE B

2

2011–11_

24

FT500A.55.020

LIFTING ARM ASSEMBLY

2

2011–11_



25



FT500B.55.127



LIFTING ARM PRESSURE PLATE



2



2011–11_

28

300.55.134

SAFTY VALVE BODY OF CYLINDER

1

2011–11_

29

300.55.133

SAFTY VALVE SPRING OF OIL CYLINDER

1

2011–11_

30

300.55.131–132

ADJUSTING WASHER

999

2011–11_

31

300.55.130

PLUG

1

2011–11_



34



25.55.146L



PUSH ROD SLEEVE



1



2011–11_

35

25.55.145L

FORCE ADJUSTING SEAL SLEEVE

1

2011–11_

38

25.55.158

SPRING ROD

1

2011–11_

39

25.55.159

SPRING SEAT

1

2011–11_

4

E300.55.140A

SPEED DROP VALVE HAND WHEEL

1

2011–11_



4



E300.55.140A



SPEED DROP VALVE HAND WHEEL



1



2011–11_

40

25.55.157

FORCE ADJUSTING SPRING

1

2011–11_

41

25.55.160

SPRING PRESSURE PLATE

1

2011–11_

43

FT500A.55.128

UPPER SUSPENSION POINT ROCKER SEAT

1

2011–11_

44

450.55.167

ROCKER CONNECTING PIN

1

2011–11_

218












219





FT300.55B.001–2 55.2–༵ืഗጺׯ–2(Ⴤ)



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

46

FT500B.55.152

ROCKER FRONT CONNECTING PIN

1

2011–11_

47

25.56.030

LOCKING PIN AND RING ASSEMBLY

1

2011–11_

48

FT500A.55.106

ROCKER UPPER CONNECTING PIN

1

2011–11_

49

FT500B.55.130

UPPER JOINT ROCKER ARM

1

2011–11_

51

25.55.162

DUSTPROOF COVER

1

2011–11_



52



YT300A.55.121



UPPER PULL ROD CONNECTING JOINT



1



2011–11_

53

25.55.161

NUT

1

2011–11_

54

FT500A.55.103

UPPER COVER PAPER GASKET

1

2011–11_

55

FT500A.55.104B

LIFTER UPPER COVER

1

2011–11_

59

FT500A.55.110

LIFTING SHAFT

1

2011–11_



60



FT500B.55.122A



SHAFT SLEEVE



1



2011–11_

63

FT300.55B.019A

INNER ARM AND PISTON MANDRIL ASSEMBLY

1

2011–11_

63

FT300.55B.019A

INNER ARM AND PISTON MANDRIL ASSEMBLY

1

2011–11_

63

FT500B.55.113E

INNER LIFTING ARM

1

2011–11_

64

FT500B.55.114D

PISTON TOP ROD

1

2011–11_



66



KM550.55.105–1



SHAFT SLEEVE



1



2011–11_

67

KM550.55.109

CAM

1

2011–11_

68

FT500B.55.104B

SHAFT SLEEVE

1

2011–11_

7

FT500B.55.120

WASHER

1

2011–11_

70

FT500A.55.123

OIL CONVEYING PIPE NUT

1

2011–11_



72



FT500B.55.140



HYDRAULIC OUTLET PIPE JOINT



1



2011–11_

74

FT500B.55.105

OIL OUTLET PIPE

1

2011–11_

76

JB982–22

COMBINED SEAL GASKET

1

2011–11_

78

FT500B.55.126

INTERCEPTING VALVE ADJUSTING ROD

1

2011–11_

79

BY350.55.163

ADJUSTING VALVE SOLENOID HANDLE

1

2011–11_

220












221





FT300.55B.001–2 55.2–༵ืഗጺׯ–2(Ⴤ)



Քࡽ No.

پࡽ Code

ఁ׬ Detcription

ຕଉ Ruantity

Ԣጀ Renark

8

80

9

FT500B.55.121 YT300A.55.122 FT500B.55.125

LOCK SHIM

INTERCEPTING VALVE LIMIT PLATE OIL CYLINDER BOLT

1

1

2

2011–11_

2011–11_

2011–11_

222




















223
