Description

QC4115T-05001 QUANCHAI PISTON

TG1204.53 Tow mechanism assembly 1
1 TG1204.53.1 Traction frame weldment 1
2 TG1204.53-02 Tow pin 2
3 GBT899-GM16-M16X200-A2L Stud 8
4 GBT93-16-AOP Washer 8
5 GBT6170-M16-AOP Nut 8
6 FT800.53.111 Spring lock pin 1
7 TG1204.53-01 Tow bracket 1
8 FT800.53.102 Pothook pin 1
9 FT800.35.112 Spring lock pin 2

TG1204.551 Lifting Device Assembly 1
1 TG1204.551.2 Lift housing press-fitting assembly 1
1.1 TG1204.551.2-02 Copper shaft sleeve 4
1.2 TG1204.551.2-01 Lift housing 1
2 JBT7940.1-M10X1 Through forced filling oil cup 2
3 TG1204.551-05 Bush 1
4 GBT5783-M16X55-A3L Hex bolt 8
5 GBT93-16-AOP Standard spring washer 14
6 TG1204.551.3 Right lift arm assembly 1
6.1 TG1204.551.3-01 Right lift arm 1
6.2 TG1204.551.3-03 Copper sleeve 1
6.3 TG1204.551.3-02 Buttonhead 1
6.4 JBT7940.1-M10X1 Through forced filling oil cup 1
7 TG1204.551.5 Lift right end cover assembly 1
7.1 TG1204.551.5-03 Lift right end cover 1
7.2 TG1204.551.5-01 Limit board 1
7.3 TG1204.551.5-02 Steering shaft 1
8 GBT93-10-AOP Standard spring washer 4
9 GBT5783-M10X30-A3L Hex bolt 2
10 TG1204.551.1 Oil cylinder assembly 2
10.1 TG1204.551.1-01 Shaft bush 2
11 TG1204.551-03 Oil cylinder pin shaft lock piece 2
12 GBT93-12-AOP Standard spring washer 4
13 GBT5783-M12X30-A3L Hex bolt 4
14 TG1204.551-02 Oil cylinder pin shaft 2
15 TG1204.551.4 Left lift arm assembly 1
15.1 JBT7940.1-M10X1 Through forced filling oil cup 1
15.2 TG1204.551.3-03 Copper sleeve 1
15.3 TG1204.551.3-02 Buttonhead 1
15.4 TG1204.551.4-01 Left lift arm 1
16 GBT1096-20X12X80 Flat key 2
17 TG1204.551-01 Lift shaft 1
18 TG1204.551-04 Lift shaft pressure plate 1
19 GBT5783-M10X25-A3L Hex bolt 2
20 GBT5783-M16X65-A3L Hex bolt 6

TG1454.552C Distributor and oil pipe assembly 1
1 GBT3452.1-17.0X2.65G O-ring sealant used for hydraulic or pneumatic parts 1
2 TG1454.552A-03 Cover plate 1
3 GBT93-10-A0P Standard spring washer 6
4 GBT5783-M10X25-8.8-A3L Hexagon head bolt 8
5 TG1204.552.4 Cylinder safety valve assembly 1
5.1 GBT91-2X36-A0P Cotter pin 1
5.2 FT700.55.172 Pressure regulating stud 1
5.3 GBT3452.1-23.6X2.65G O-ring sealant used for hydraulic or pneumatic parts 1
5.4 GBT3452.1-10.6X2.65G O-ring sealant used for hydraulic or pneumatic parts 1
5.5 FT65.55.147 Cylinder safety valve spring 1
5.6 FT700.55.146 Cylinder safety valve body 1
5.7 FT700.55.145 Safety valve seat 1
5.8 GBT3452.1-19.0X2.65G O-ring sealant used for hydraulic or pneumatic parts 1
5.9 TG1204.552.4-01 Cylinder safety valve housing 1
5.1 GBT3452.1-17.0X2.65G O-ring sealant used for hydraulic or pneumatic parts 1
6 GBT6170-M10-8-A3L Hexagon nut, style 1 3
7 TG1454.552A-01 Safety valve connecting plate 1
8 GBT5782-M10X80-8.8-A2L Hexagon head bolt 3
9 JBT982-16 Compound seal washer 2
10 GBT3733.2-G12 Straight thread connector, body 2
11 TG1454.552A.5 Safety valve oil return pipe assembly 1
12 TG1204.552-03a By-pass valve block 1
13 GBT93-12 Standard spring washer 4
14 GBT5782-M12X70-8.8-A2L Hexagon head bolt 4
15 JBT982-20 Compound seal washer 4
16 TG1204.552-04 Hollow bolt M20X1.5 2
17 TG1454.552A.4 Oil cylinder oil inlet pipe assembly 3 1

TG1454.552C Distributor control and oil pipe assembly 1
1 TG1454.552A.12 Control crank assembly 1
1.1 TG1454.552A.12.1 Control crank weldment 1
1.2 TG1454.552A.12.2 Feedback lever weldment 1
1.3 TG1204.552.12-04 Nylon bush 1
1.4 GBT97.1-12-A0P Plain washer 1
1.5 GBT91-2X20-A0P Cotter pin 1
1.6 GBT6172.1-M10-04-A3L Hexagon thin nut 2
2 TG1204.552-06 Hollow bolt M24X1.5 1
3 JBT982-24 Compound seal washer 2
4 TG1454.552.3 Distributor oil inlet pipe assembly 1
5 JBT982-22 Compound seal washer 2
6 FT300.58.101 Hollow bolt 1
7 TG1204.552-07 Hollow bolt M20X1.5 1
8 JBT982-20 Compound seal washer 7
9 TG1204.552-08 Thick washer 1
10 TG1204.552-04 Hollow bolt M20X1.5 2
11 TG1454.552.2 Cylinder oil inlet pipe assembly 2 1
12 JBT982-27 Compound seal washer 3
13 TG1204.552B-02 Spacing sleeve 1
14 TG1454.552A.1 Distributor oil return pipe weldment 1
15 TG1204.552B-01 Hollow bolt M27X1.5 1
16 Q67638 B-type worm transmission hose clamp 2
17 TG1854.581-12 Oil suction hose 3 1
18 GBT5783-M10X25-8.8-A3L Hexagon head bolt 5
19 GBT93-10-A0P Standard spring washer 5
20 TG1204.552.11 Distributor bracket weldment 1
21 TG1454.552C.3 Cylinder oil inlet pipe assembly 1 1
22 TG1454.552A-02 Straight thread connector, body 1
23 TG1204.552A.2 Distributor assembly 1

TG1454.552C Distributor control and oil pipe assembly 1
1 JBT982-20 Compound seal washer 14
2 TG1454.552C-01 Slow down valve body 2
3 FT650.40.102 Hollow bolt M20X1.5 2
4 TG1454.552C.4 Cylinder oil pipe assembly 1 2
5 TG1454.552C.2 Slow down valve assembly 2 2
6 TG1204.552-10 Hollow bolt M20X1.5 2
7 TG1454.552C.3 Cylinder oil pipe assembly 2 2
8 TG1204.552-11 Thick washer-2 2
