Description

QC4110T QUANCHAI PISTON RING

TS08452040000K Floor Assembly 1
1 GBT5783-M8X20-8.8-A2L Hexagon Bolt 4
2 GBT93-8-A0P Standard Spring Washer 10
3 GBT97.1-8-A0P Flat Washer 4
4 TS08452040001K Floor Weldment 1
5 TS08452030073K Cover Plate Weldment 1
6 TG1254.452-12 Rear Lower Window Glass Seal Strip 1
7 TG1254.452-11 Rear Lower Window Glass 1
8 GBT6170-M5-8-A2L Hexagon Nut, Type-1 8
9 TD800.452-07 Glass Clamp 8
10 GBT97.1-5-A0P Flat Washer 14
11 GBT93-5-A0P Standard Spring Washer 14
12 GBT5783-M5X20-8.8-A2L Hexagon Bolt 8
13 FT800A.45.130 Dustproof Sleeve 1
14 TG1254.452-19 Retainer Plate 1
15 GBT5783-M5X10-8.8-A2L Hexagon Bolt 6
16 TS08452030029K Front Floor Mat 1
17 TG1654.452E.5 Pedal Installation Assembly 1
17.1 GBT97.1-10-A0P Flat Washer 3
17.2 GBT93-10-A0P Standard Spring Washer 3
17.3 TG1654.452E.5.1 Pedal Weldment 1
17.4 GBT5783-M10X35-8.8-A3L Hexagon Bolt 3
18 TG1654.452E.6 Pedal Installation Assembly （Right） 1
18.1 GBT97.1-10-A0P Flat Washer 3
18.2 GBT93-10-A0P Standard Spring Washer 3
18.3 GBT5783-M10X35-8.8-A3L Hexagon Bolt 3
18.4 TG1654.452E.6.1 Pedal Weldment （Right） 1
19 GBT5783-M8X16-8.8-A2L Hexagon Bolt 2
20 GBT95-8-A0P Flat Washer 2
21 TG1554.452C.1.2-01 Plug Plate 1
22 TG1554.452-01 Bonnet Bracket（Left） 1
23 GBT5783-M8X25-8.8-A2L Hexagon Bolt 4
24 TG1554.452-02 Bonnet Bracket（Right） 1
25 GBT96.1-5-A0P Big Washer 8

TS08452040000K Floor Assembly 1
1 TD904.452.4 Rearview Mirror Assembly 2
2 TD800.452Y.2 Right Rear View Mirror Bracket Weldment 1
3 TD800.452Y.1 Bracket Weldment Of Left Rearview Mirror 1
4 GBT5783-M8X30-8.8-A2L Hexagon Bolt 8
5 GBT93-8-A0P Standard Spring Washer 8
6 GBT97.1-8-A0P Flat Washer 8
7 TS08452030079K Right Rear Connecting Installation 1
7.1 GBT5783-M16X80-8.8-A3L Hexagon Bolt 2
7.2 GBT97.1-16-A0P Flat Washer 4
7.3 GBT93-16-A0P Standard Spring Washer 2
7.4 GBT6170-M16-8-A3L Hexagon Nut, Type-1 2
7.5 GBT5782-M20X110-A3L Hexagon Bolt 1
7.6 GBT96.1-20-A0P Big Washer 1
7.7 TD800.457B.1-01 Retainer Ring 2
7.8 TD800.457B.1.2 Shock Absorber 1
7.9 TG1654.452E.3.1 Right Rear Connecting Weldment 1
7.10 GBT95-20-A0P Flat Washer 1
7.11 GBT93-20-A0P Standard Spring Washer 1
7.12 GBT6170-M20-A9L Hexagon Nut, Type-1 1
8 TG1654.452E.4 Front Connecting Assembly 2
8.2 TD800.457B.1.2 Shock Absorber 1
8.1 TD800.457B.1-01 Retainer Ring 2
8.3 GBT96.1-20-A0P Big Washer 1
8.4 GBT93-20-A0P Standard Spring Washer 1
8.5 GBT5782-M20X90-8.8-A9L Hexagon Bolt 1
9 TS08452030078K Left Rear Connecting Installaion 1
9.1 GBT5783-M16X80-8.8-A3L Hexagon Bolt 2
9.2 GBT97.1-16-A0P Flat Washer 4
9.3 GBT93-16-A0P Standard Spring Washer 2
#N/A
9.4 GBT6170-M16-8-A3L Hexagon Nut, Type-1 2
9.5 GBT5782-M20X120-10.9-A3L Hexagon Bolt 1
9.6 GBT96.1-20-A0P Big Washer 1
9.7 TS08452030080K Retainer Ring 2
9.8 TD800.457B.1.2 Shock Absorber 1

9.9 TG1654.452E.2.1 Left Rear Connecting Weldment 1
9.10 GBT95-20-A0P Flat Washer 1
9.11 GBT93-20-A0P Standard Spring Washer 1
9.12 GBT6170-M20-8-A9L Hexagon Nut, Type-1 1
10 TG1254.452-13 Gearshift Cover Plate 1
11 FT300.45.809 Upper Cover Press Strip 1
